Recognition Error ID Item Description

01 39 2 14001 “# of Types” (elctd data) is improper. ----

01 39 2 14002 “# of Groups” (elctd data) is improper. ----

01 39 2 14003 “Elctd Type No.” in “Elctd Group 1” is improper. ---

01 39 2 14004 “Elctd Type No.” in “Elctd Group 2” is improper. ----

01 39 2 14005 “Elctd Type No.” in “Elctd Group 3” is improper. ----

01 39 2 14006 “Elctd Type No.” in “Elctd Group 4” is improper. ----

01 39 2 14007 “Elctd Type No.” in “Elctd Group 5” is improper. ----

01 39 2 14008 “Elctd Type No.” in “Elctd Group 6” is improper. ----

01 39 2 14009 “Elctd Dim” in “Elctd Group 1” is larger than ----

“Elctd Row or Col Pitch”.

01 39 2 14010 “Elctd Dim” in “Elctd Group 2” is larger than ----

“Elctd Row or Col Pitch”.

01 39 2 14011 “Elctd Dim” in “Elctd Group 3” is larger than ----

“Elctd Row or Col Pitch”.

01 39 2 14012 “Elctd Dim” in “Elctd Group 4” is larger than ----

“Elctd Row or Col Pitch”.

01 39 2 14013 “Elctd Dim” in “Elctd Group 5” is ----

larger than “Elctd Row or Col Pitch”.

01 39 2 14014 “Elctd Dim” in “Elctd Group 6” is ----

larger than “Elctd Row or Col Pitch”.

01 39 2 14015 “Missing Start Row or Col” in Elctd Group 1" is ----

too large.

01 39 2 14016 “Missing Start Row or Col” in Elctd Group 2" is ----

too large.

01 39 2 14017 “Missing Start Row or Col” in Elctd Group 3" is ----

too large.

01 39 2 14018 “Missing Start Row or Col” in Elctd Group 4" is ----

too large.

01 39 2 14019 “Missing Start Row or Col” in Elctd Group 5" is ----

too large.

01 39 2 14020 “Missing Start Row or Col” in Elctd Group 6" is ----

too large.

(Cause) Wrong parameters are set.

(Remedy) Set correct parameters.

01 10-003 2-169 AFO01ETRP

4.3 Recognition Error IDs and Remedial Procedures

Recognition Error ID Item Description

01 39 2 14021 “Polarity Inspection Position” Out of “Mold Size” ----

01 39 2 14022 “Elctd # of Rows or # of Cols” in "Elctd Group 1" ----

is Not Sufficient

01 39 2 14023 “Elctd # of Rows or # of Cols” in "Elctd Group 2" ----

is Not Sufficient

01 39 2 14024 “Elctd # of Rows or # of Cols” in "Elctd Group 3" ----

is Not Sufficient

01 39 2 14025 “Elctd # of Rows or # of Cols” in "Elctd Group 4" ----

is Not Sufficient

01 39 2 14026 “Elctd # of Rows or # of Cols” in "Elctd Group 5" ----

is Not Sufficient

01 39 2 14027 “Elctd # of Rows or # of Cols” in "Elctd Group 6" ----

is Not Sufficient

01 39 2 14028 Electrode Position Superposed in Different ----

Electrode Group!

01 39 2 21001 Failed in Automatic Selection of Algorithm for ----

Lealess Components.

01 39 2 21002 Failed in Automatic Selection of Algorithm for ----

Leaded Components.

01 39 2 21003 Failed in Automatic Selection of Algorithm for ----

Area Array.

01 39 2 21004 Failed in Automatic Selection of Algorithm for ----

Cylindrical Components.

01 39 2 21005 Failed in Automatic Selection of Algorithm for ----

Square Components.

01 39 2 21006 Failed in Automatic Selection of Algorithm for ----

Deformed Components.

01 39 2 21007 Failed in Automatic Selection of Algorithm for ----

ICs.

01 39 2 21008 Failed in Automatic Selection of Algorithm for ----

Connectors.

01 39 2 21009 Failed in Automatic Selection of Algorithm for ----

Leaded Components.

01 39 2 21010 Failed in Automatic Selection of Algorithm for ----

BGA Components.

01 39 3 00005 Error in “Component Library Pickup Pos ----

Correction X or Y” Data.

(Cause) Wrong parameters are set.

(Remedy) Set correct parameters.

01 10-003 2-170 AFO01ETRP

4.3 Recognition Error IDs and Remedial Procedures

Recognition Error ID Item Description

01 39 3 10001 “Component Library Polarity Component shape” ----

Not Supported!

(Cause) The data is not supported.

(Remedy) Set the supported data.

01 39 3 11001 Error in “Component Library Mold Size X or Y” ----

Data

01 39 3 11002 Error in “Component Library Mold Size T or t or ----

Ut” Data

01 39 3 11003 Error in “Component Library Outward Length” ----

Data

(Cause) Wrong parameters are set.

(Remedy) Set correct parameters.

01 39 3 12001 “Component Library Component type” Not ----

Supported!

(Cause) The data is not supported.

(Remedy) Set the supported data.

01 39 3 12002 Error in “Component Library Elctd Size” Data ----

01 39 3 12112 Error in “Component Library Corner Dim X or Y” ----

Data

01 39 3 12212 Error in “Component Library Edge Detection ----

Posn” Data

01 39 3 12301 Error in “Component Library Number of Linear ----

Edges” Data

01 39 3 12311 Error in “Component Library Linear Start ----

Position” Data

01 39 3 12312 Error in “Component Library Linear Direction” ----

Data

01 39 3 12313 Error in “Component Library Linear Width ----

(Length)” Data

(Cause) Wrong parameters are set.

(Remedy) Set correct parameters.

01 10-003 2-171 AFO01ETRP

4.3 Recognition Error IDs and Remedial Procedures
