1.3 Machine lnformation 01 10-003 2 - 9 AFO01ETRP 1.3 Machine Information 1.3.1 “Machine Information” Window • • • • • Window Layout V arious machine information is displayed while the machine is running. While the “Mach…
Check Code Display Section A Display Section B
0b0136 Feeder Carriage Not Press the [F1B READY] button to set feeder carriage #1 in ready
Ready Switch mode.
0b0201 Operation Area Feeder Close saf. guard at crg. home pos. 1.
Axis Safety Guard
0b0202 Operation Area Feeder Close saf. guard at crg. home pos. 2A.
Axis Safety Guard
0b0203 Operation Area Feeder Close saf. guard at crg. home pos. 3B.
Axis Safety Guard
0b0204 Operation Area Feeder Close saf. guard at crg. home pos. 2B.
Axis Safety Guard
0b0205 Operation Area Feeder Close saf. guard at crg. home pos. 3A.
Axis Safety Guard
0b0206 Operation Area Feeder Close saf. guard at crg. home pos. 4.
Axis Safety Guard
0b0211 Operation Area Feeder Close saf. guard at crg. home pos. 1.
Axis Safety Guard
0b0216 Operation Area Feeder Close saf. guard at crg. home pos. 2.
Axis Safety Guard
0b0221 Operation Area Feeder Close saf. guard at crg. home pos. 12.
Axis Safety Guard
0b0226 Axis Safety Guard Close saf. guard at crg. home pos. 34.
0b0231 Operation Area Feeder Close saf. guard at crg. home pos. 1A.
Axis Safety Guard
0b0236 Operation Area Feeder Close saf. guard at crg. home pos. 1B.
Axis Safety Guard
0d0101 Out Of Origin Zero X/Y chute width.
0d0102 Out Of Origin Zero L conveyor width.
0d0103 Out Of Origin Zero R conveyor width.
0d0104 Out Of Origin Zero conveyor width.
0d0105 Out Of Origin Zero all devices with the [ZERO] button.
0d0106 Out Of Origin Zero PCB support pins up/down.
0d0107 Out Of Origin Zero PCB locate lever.
0d0108 Out Of Origin Zero X/Y table axis.
0d0109 Out Of Origin Zero camera X/Y axis.
0d0201 Feeder Axis Servo Check F1 saf. guard if open/close.
Down
0d0202 Feeder Axis Servo Check F2 saf. guard if open/close.
Down
0d0203 Feeder Axis Servo Check F3 saf. guard if open/close.
Down
0d0204 Feeder Axis Servo Check F4 saf. guard if open/close.
Down
01 10-003 2-8 AFO01ETRP
1.2 “CHECK” Windows
1.3 Machine lnformation
01 10-003 2-9 AFO01ETRP
1.3 Machine Information
1.3.1 “Machine Information” Window
••
••
•
Window Layout
Various machine information is displayed while the machine is running.
While the “Machine Information” window is active, the machine
keeps on running.
Note
Fig. 4B2-1 Example of “Machine Information”
••
••
•
Window Composition
*1 Machine Information
The machine information is displayed.
Refer to “1.3.2 List of Check Messages” for details.
Note
01 10-003 2-10 AFO01ETRP
*2 Display Section A
Displayed is the outline of the machine information.
*3 Display Section B
Displayed are the details of the machine information.
*4 [OK] Button
When pressed, this button closes the "Machine Information" window.
*5 [Clear Alarm] Button
When pressed, this button cancels an alarm (sound) only.
1.3 Machine lnformation
