MODEL FP-G100L 1004-004 Key No. P AR T No. P AR T NAME Q’ty REMARKS New Code NOTE TL-4 list-1 TL-4 304 6301313610 COVER 1 845G-A100020-A004 21 1A9201 845G-A100050-A004 305 6301313634 BRACKET 1 845G-A100020-A005 21 1F8959…
MODEL FP-G100L
0801-002
TL-4 illust-1
トラバース部
TRAVERSE SECTION
Fig. TL-4
カバー
Cover
306
304
305
See Fig. TL-1
Key No.38
See Fig. EL-8
Key No.722
MODEL FP-G100L
1004-004
Key No. PART No. PART NAME Q’ty REMARKS New Code
NOTE
TL-4 list-1
TL-4
304 6301313610 COVER 1 845G-A100020-A004 211A9201
845G-A100050-A004
305 6301313634 BRACKET 1 845G-A100020-A005 211F8959
845G-A100050-A005
306 6301313641 BRACKET 1 845G-A100020-A006 211F8960
845G-A100050-A006
