25
TS500 Series
Smart Valve Controllers
Smart Valve Controllers - Key Features
• TouchScreeninterfaceforeasysetupandoperation
• Industry4.0for“SmartFactory”integration
• Universalpowersupplyforworldwideuse
• Digitalpressureregulatorforprecisecontrol
•
Digital timing control for repeatable output
The TS550R Smart Valve Controller is capable of controlling all
Techcon pneumatic valve series including: TS1212 Pinch Tube
Valve, TS941/TS5322 Spool Valve, TS5420/TS5440 Needle
Valves and TS5620/TS5622 Diaphragm Valves.
The TS560R Smart Spray Valve Controller is capable of control-
ling all Techcon TS5520 and TS5540 Spray Valves.
The TS570R Smart Auger Valve Controller is capable of con-
trolling all Techcon TS5000 and TS7000 Auger Valves.
The TS580R Smart PC Pump Controller is capable of control-
ling all Techcon TS8100 series PC Pumps.
Typical Applications
Conformal coating, lubrication and
marking application.
Typical Applications
Solder paste dispensing, encapsulation
and potting applications.
Typical Applications
Underfilling PCBA components,
encapsulation and potting applications,
applying lubrication on automotive parts,
and dispensing pastes and flux.
Part Number Description
TS560R Smart Spray Valve Controller
Part Number Description
TS570R Smart Auger Valve Controller
Part Number Description
TS550R Smart Pneumatic Valve Controller
Typical Applications
Control diaphragm valve for bonding applica-
tion, control mini-spool valve for form-inplace
gasket, and control needle valve for precision
filling process.
Part Number Description
TS580R Smart PC Pump Controller
26
www.techcon.com
www.techcon.com www.techcon.com
TS1254/1258
Pressure Pot
TS1254 - Pressure potTS918-46 - Four-way Manifold
TS1258 - Pressure pot
Specifications - Pressure Pot
TS1258
Size 10" x 15.1" (254 x 383mm)
Chamber 6.1" I.D. x 11.0" (155 I.D. x 280mm)
Weight 21 lb. (9.5 kg)
Max Operating Pressure 100 psi (6.9 bar)
Internal Volume 5 liters
TS1254
Size 7.5" x 12.5" (190 x 318mm)
Chamber 4.75" I.D. x 6.5" (121 I.D. x 165mm)
Weight 10.4 lb. (4.7 kg)
Max Operating Pressure 70 psi (4.8 bar)
Internal Volume 1.8 liters
TS1254/1258
Pressure Pot
The Pressure Pot is designed to accommodate low to medium
viscosity fluid including solvents, adhesives, as well as CAs and
UVs. The fluid feed line is located in the center of the unit for a
direct and continuous feed path from the reservoir to the dis-
pensing valve. The TS1258 is shipped with a 1/4" tubing and the
TS1254 is shipped with a 6mm tubing. For use with the TS1212 or
TS1201 valve, a TS1252-4MM Fluid Line kit is needed.
TS918
Four-way Manifold
Designed to provide equal flow for up to four fluid paths, the
TS918-46 is used whenever precision fluid flow to multiple sta-
tions is required. The Manifold works with the TS1258 Pressure
Pot (TS1258-375 Hose Kit required to use TS918-46 and TS1258
together). Made from Delrin® and suitable with UV materials.
The manifold can be used with any Techcon Systems Valve.
Specifications - TS918-46 Four-way Manifold
Size 2.6" x 2.2" (66 x 56mm)
Inlet Port
1/4" NPT (3/8” O.D. tube tting is included)
Outlet Port
1/8" NPT (4 Luer Lock ttings are included)
Max Operating Pressure 100 psi (6.9 bar)
Mounting 1/4”-20UNC-2B (x2)
Available Fluid Line Kits (Includes clear and black tubing)
For the TS1258 Pressure Pot
TS1252-4MM
4mm O.D. tube (required for TS1212 and TS1201 connection)
TS1258-250 1/4" O.D. tube
TS1258-375 3/8" O.D. tube
For the TS1254 Pressure Pot
TS1252-4MM
4mm O.D. tube (required for TS1212 and TS1201 connection)
254-250PE 6mm O.D. tube PE
TOUCH
SCREEN
TS550R
Typical Valve Set Up
www.techcon.com
www.techcon.com www.techcon.com
27
Valve Application Guide
Valve Version
Pinch
(TS1212)
Needle
(TS5420)
Micro
Needle
(TS5440)
Mini
Spool
(TS5322)
HP
Spool
(TS941)
Diaphragm
(TS5620)
1
(TS5624DMP)
2
Rotary DMP
(TS5000DMP)
Rotary
(TS7000)
Spray
(TS5540)
Jet
(TS9000)
PC Pump
(TS8100)
Micro shots
8
u
4
u
8
u u u
4 8 4
u
Dots
4 4 4 4 4 4 4 4 4 8 4 4
Lines/Beads
4 4 4 4 4 4 4 4 4 8 4 4
Potting & Encapsulation
u u u
4 4 4 4 4 4 8 8 4
Packaging/Filling
4 4 4 4 4 4 4
u u
8 8 4
High Pressure
8 8 8 4 4 8 8 8 8 8 8 8
Sprayed
8 8 8 8 8 8 8 8 8 4 8 8
Jetting
8 8 8 8 8 8 8 8 8 8 4 8
Viscosity
High
8 8 8 4 4 8 8 4 4 8 4 4
Medium
8 8
u
4 4 8 8 4 4 8 4 4
Low
4 4 4
u u
4 4 8 8 4 4 4
Application
Activators
4 4 4
u u
4 4 8 8 4 4 4
Alcohol
4 4 4
u u
4 4 8 8 4
u
4
Anaerobics
4 8 8 8 8 4 4 4 8 8 8
u
Brazing Paste
8 8 8 8 8 8 8 8 4 8 8
u
Conformal Coatings
8
u u u u
4 4 8 8 4
u u
Cyanoacrylates
4 8 8 8 8 4 4 8 8 8 8 8
Epoxies
u u u u u
8
u
4 4 8 4 4
Flux (liquid)
4 4 4
u u
4 4 8 8 4 4 4
Flux (paste)
8 8 8 4 4 8 8 4 4 8 4 4
Greases
8 8
u
4 4 8 8 4 4 8 4 4
Inks
4 4 4
u u
4 4 8 8 4
u
4
Lacquers
u u
4
u u
4 4 8 8 4 4 4
Mold Releases
4 4 4
u u
4 4 8 8 4 8 4
Oils
4 4 4
u u
4 4 8 8 4 4 4
Paints
4 4 4
u u
4 4 8 8 4 4 4
Reagent
u
4 4 8 8 4 4 8 8 4 4 4
RTV Silicone
8 8 8 4 4 8 8 4 4 8
u
4
Solder masks
4
u u
4 4 4 4 8 8 8 4 4
Solder pastes
8 8 8
u u
8 8
u
4 8 8 4
Solvents
4 4 4 8 8 4 4 8 8 4 4 4
Two-part adhesive
4 8 8 8 8 8 4 4 8 8 8 8
UV cure/adhesive (liquid)
u
8 4
u
8 4 4 8 8 4 4 4
UV cure/adhesive (gel)
8 8 4 4 8 8 8 4 4 8 4 4
UV cure with anaerobic
4 8 8 8 8 4 4 4 8 8 8
u
Excellent -
4 Average - u Do not use - 8
1 2
Disclaimer: The valve application guide is for reference only.
Please contact a Techcon applications engineer for accurate valve recommendation.
