Page 14
T46230811 Rev. J DH Positioning System Assembly, Non P/T
This Document Supports Assembly 46230811 Rev J
DET
NO.
ITEM NO. DESCRIPTION QTY U/M
32 80000604 SHCS 1/4-20 X 5/8 9 EA
33 15102001 PULLEY,GEARBELT 3 EA
34 80005803 SSSCNP 10-24 X 1/2 3 EA
35 46684301 BEARING,BALL 2 EA
36 80001302 SBHS 4-40 X 3/8 6 EA
37 40834608 STANDOFF 4 EA
38 20266000 SHAFT 1 EA
39 15092000 GEARBELT 1 EA
40 46991003 RETAINER, BELLOW 1 EA
41 80000707 SHCS 5/16-18 X 1 1/4 1 EA
42 17691000 SUPPORT,BRG 1 EA
43 10593001 BEARING,BALL 2 EA
44 17689000 BLOCK,BRG 1 EA
45 80015103 HEX,JAM NUT 5/16-18 2 EA
46 14330003 RETAINER, BELLOW 2 EA
47 22260003 VINYL/.25 FOAM 1 EA
48 42039202 COVER,BOTTOM 1 EA
49 80008721 PHMS 10-32 X .38 4 EA
50 80018704 SLW #8 23 EA
51 22260002 VINYL/.25 FOAM 1 EA
52 17258075 .50 INSULATION 2 EA
53 45048001 COVER,FRONT 1 EA
55 48344301 HDW,STDF,10-32,1/2 IN,STL,M/F 2 EA
56 80018804 FW #8 18 EA
57 17656001 PLATE,MTG. 1 EA
58 80001602 SBHS 10-24 X 3/8 4 EA
59 17700001 COVER,Y FRAME 1 EA
60 80001402 SBHS 6-32 X 3/8 8 EA
61 45336503 RIGHT, COVER ASSY 1 EA
62 BLKM07423 HEX STANDOFF 7 EA
Page 15
DH Positioning System Assembly, Non P/T T46230811 Rev. J
This Document Supports Assembly 46230811 Rev J
DET
NO.
ITEM NO. DESCRIPTION QTY U/M
63 22243017 VINYL, DAMPING 2 EA
64 22243011 VINYL, DAMPING 4 EA
65 22243016 VINYL, DAMPING 1 EA
66 20467001 COVER, BACK 1 EA
67 45336603 LEFT COVER ASSY 1 EA
68 80014904 SPRING PIN 1 EA
69 18333000 COLLAR 4 EA
70 80010102 DOWEL 1/4 DIA X 5/8 17 EA
71 30647602 GUARD 2 EA
72 80001609 SBHS 10-32 X 3/8 9 EA
73 80018806 FW #10 35 EA
74 80018705 SLW #10 57 EA
75 45290501 COVER, WELDMENT 2 EA
76 80018706 SLW 1/4 8 EA
77 80001704 SBHS 1/4-20 X 3/4 12 EA
78 80018807 FW 1/4 5 EA
79 17258081 .50 INSULATION 4 EA
80 17258079 .50 INSULATION 4 EA
81 17258080 .50 INSULATION 4 EA
82 80010506 DOWEL 1/2 DIA X 2 1 EA
83 20619001 SHIELD 1 EA
84 80001701 SBHS 1/4-20 X 3/8 3 EA
85 BLKM06742 STANDOFF 3 EA
86 80001011 SHCS 1/2 -13 X 2 1/2 6 EA
87 23279001 SHIELD 2 EA
88 80001812 SBHS 5/16-18 X 1 1/4 2 EA
89 BLKM06741 STANDOFF 2 EA
90 80001501 SBHS 8-32 X 1/4 4 EA
91 40200106 C-FRAME 1 EA
92 22243014 VINYL DAMPING 4 EA
Page 16
T46230811 Rev. J DH Positioning System Assembly, Non P/T
This Document Supports Assembly 46230811 Rev J
DET
NO.
ITEM NO. DESCRIPTION QTY U/M
93 30587602 BRACKET,LOCKING 8 EA
94 30780801 SPACER 8 EA
95 80001606 SBHS 10-24 X 7/8 8 EA
96 80002503 SFHS 8-32 X 5/8 6 EA
97 30648002 DRIVE ASSY 2 EA
98 80002612 SFHS 10-32 X 1 4 EA
99 80023508 HEX NUT-MS 10-32 4 EA
100 BLKE01073 CABLE CLAMP,5/16,BLACK 2 EA
101 80008602 PHMS 8-32 X 1/4 2 EA
102 42372703 X FRAME 2 EA
103 15055000 BUSHING,BALL 8 EA
104 30013000 PLUNGER, SPRING 8 EA
105 18388000 RETAINER 8 EA
106 46194802 BLOCK,SUPPORT 1 EA
107 80000606 SHCS 1/4-20 X 7/8 2 EA
108 48253601 BELLOW,DUST 1 EA
109 80010003 DOWEL 3/16 DIA X 3/4 1 EA
110 80000603 SHCS 1/4-20 X 1/2 10 EA
111 80000110 SHCS 4-40 X 5/16 8 EA
112 48240101 PLATE,MOTOR 1 EA
113 80001610 SBHS 10-32 X 1/2 12 EA
114 42372601 TROLLEY,ROT 2 EA
115 46587901 GEAR BELT 2 EA
116 17615000 CAM 2 EA
117 18058000 LOCK ASSY 2 EA
118 40395901 MECH SLOWDOWN ASSY 1 EA
119 80007601 HHCS 1/4-20 X 1/2 3 EA
120 80015001 HEX NUT 1/4-20 1 EA
121 40395902 MECH SLOWDOWN ASSY 1 EA
122 40395803 PULSE VALVE ASSY 1 EA
