N2 Co ns ump ti o n Re d uc t io n • Test Conditions • Full co nti nuo us l oa d co ndi ti on – 4 x 4, 12 x 12 and 18 x 18 i nch products – Entrance curtai ns tri mmed at 3/8inch above pi ns – Exi t curtai ns ful ly ex t…
Low Nitrogen Package
• 40 to 50% N
2
consumption reduction
• Customer payback less than 2 months!
– 1250 CFH down to 750 CFH, 500 CFH per hour
– 12,000 CFH per day savings (at $.01 / ft3)
= $ 120 / day
= $ 840 / week
= $3,360 / month
• Over $40,000 saving in one year!
N2 Consumption Reduction
• Test Conditions
• Full continuous load condition
– 4 x 4, 12 x 12 and 18 x 18 inch products
– Entrance curtains trimmed at 3/8inch above pins
– Exit curtains fully extended to belt
– Oxygen levels less than 50 and 1000ppm
• Configuration
– Belt / rail combination – no center support
Pyramax 125N Nitrogen Consumption
0
500
1000
1500
4 x 4 12 x 12 18 x 18
Product Size
CFH
Low N2 < 50ppm Low N2 < 1000ppm
Std <50ppm Std <1000ppm
Test Parameters
• Rail / belt combination – 18 inch width
• Entrance curtains trimmed 0.375 inches above pins
