– 159 – SIN GLE C ONVEY OR SE C TI ON 1509-002 No. Part No. Part Name Qty . Detail Y amaha Hitachi 501 KY A-M915W-00 1007A098 TUBE_D4 1 502 KY A-M915X-00 1007A099 TUBE_D32 1 503 KYB-M919J-00 0917C302 TUBE_D6 1
– 158 –
H1
6 Air Piping
1509-002
501
From Main Body
PCB Stoper (RR)
See Fig. H1-2
Key No.104
501
PCB Stoper (LR)
PCB Stoper (LL)
Z Clump (ML)
Z Clump (FL)
502
Z Clump (MR)
Z Clump (FR)
See Fig. H1-2
Key No.102
See Fig. H1-2
Key No.102
See Fig. H1-2
Key No.102
See Fig. H1-5
Key No.418
See Fig. H1-5
Key No.418
See Fig. H1-5
Key No.418
See Fig. H1-4
Key No.321
See Fig. H1-4
Key No.309
See Fig. H1-2
Key No.321
See Fig. H1-4
Key No.310
503
601
501
502
502
502
– 159 –
SINGLE CONVEYOR SECTION
1509-002
No.
Part No.
Part Name Qty. Detail
Yamaha Hitachi
501 KYA-M915W-00 1007A098 TUBE_D4 1
502 KYA-M915X-00 1007A099 TUBE_D32 1
503 KYB-M919J-00 0917C302 TUBE_D6 1
