FEEDER CART SECTION

1509-002

No.

Part No.

Part Name Qty. Detail

Yamaha Hitachi

501 KYA-M3707-00 1009EQ4L BASE

502 KYB-M372P-00 211G5359 BLOCK 4

503 KYA-M3715-00 1010E103 PLATE_GUIDE_L 2

504 91312-05016 221AA031 BOLT,HEX.SOCKET HEAD 8

505 92902-05600 221HA205 WASHER,PLAIN 8

506 90112-2AJ006 221AA145 BOLT,HEX.SOCKET HEAD 22

507 91312-03008 221AA006 BOLT,HEX.SOCKET HEAD 10

508 92902-03600 221HA203 WASHER,PLAIN 10

510 KYA-M370B-00 10094Q51 ASSY_BASE

– 42 –

– 43 –

UNDER FRAME

CONTENTS

D1 ELECTRICAL SECTION 1 44

1 Fixed Screw 44

2 Cable 46

D2 CPU BOX SECTION 48

1 CPU 1 Box 48

2 CPU 2 Box 50

D3 ELECTRICAL SECTION 2 52

1 Fixed Screw 52

2 AC Terminal 56

3 DC Terminal 58

4 Panel 60

5 XY Servo 62

6 PCB 1 64

7 PCB 2 68

D4 DC POWER SUPPLY SECTION 70

1 CPU 1 Box 70

2 ATX Power 72

3 Fan 74

D5 AIR SUPPLY SECTION 76

1 Frame Section 76

2 Air Combination Unit, Vaccum Pump 80

3 Solenoid Valve, Manifold 82
