– 74 – D4 3 Fan 1509-002 209 204 205 203 202 206 207 201 210 209 212 2 11 2 11 213 M106 215 214
– 73 –
DC POWER SUPPLY SECTION
No.
Part No.
Part Name Qty. Detail
Yamaha Hitachi
101 KYB-M410M-00 1005BA2E UNIT-POWER-ATX 1
102 KYB-M410X-00 1010BA4Y BRACKET_ATX 1
103 90990-11J010 221DA056 SCREW,PAN HEAD WW 2
110 KYB-M4100-00 1005BC4A HNS,ATX-MAIN 1
111 KYB-M4101-00 1005BC4B HNS,ATX-HD 1
112 KYB-M4102-00 1005BC4C HNS,ATX12V 1
113 KYB-M410L-00 0921A024 COIL-TUBE 1
1509-002
– 75 –
DC POWER SUPPLY SECTION
No.
Part No.
Part Name Qty. Detail
Yamaha Hitachi
201 KYA-M655S-00 1005BA4D PANEL 1
202 KYB-M658N-00 4J300191 CABLE-JOINT-TERMINAL 3
203 KYB-M852B-00 23K10390 CASE-CONN 1
204 KYB-M6588-00 23N20103 TUBE-WIRING 1
205 KYA-M410A-00 23N20113 TUBE_WIRING 1
206 KYB-MD73A-00 23N20112 TUBE_WIRING 1
207 KYB-M852E-00 23N30737 ACCESS-WIRING 1
209 KYA-M6567-00 4M130041 MOTOR-DC 1 M106
210 KYB-M65AM-00 23M00062 ACCESSORY-MOT-M 2
211 KYA-M656G-00 23M00064 ACCESSORY-MOT-M 1
212 KYB-M410J-00 0914BA17 FAN_SUPPORT 1
213 90990-09J012 221DA142 SCREW,FLAT HEAD 4
214 92902-04200 221HA104 WASHER,PLAIN 4
215 95302-04600 221FA007 NUT,HEXAGON 4
1509-002
