Page Code Discription Specification Remark 13-71 J9080120A SWING MOTOR CABLE ASS'Y MD16P 13-72 J9080121A W MOTOR PWR CABLE ASSY MD17 13-72 J9080122A W MOTOR ENC CABLE ASSY MD18 13-72 J9080123A WIDTH MOTOR CABLE ASS&…

Page Code Discription Specification Remark

13-54 J9061346C TH3 DRV COMMAND CABLE ASS'Y J9061346C(VM13)

13-54 J9080072C TRAY FEEDER CABLE ASSY VM01

13-55 J9061342D TH1/CONV DRV COMMAND CABLE ASS'Y J9061342D(VM09)

13-55 J9080079B SW/WD DRV COMMAND CABLE ASSY VM07

13-55 J9080081A Z3/4 DRV COMMAND CABLE ASSY VM10

13-56 J9061349B X AXIS ORIGIN CABLE ASS'Y MK-XA01

13-56 J9080083A X AXIS +LIMIT CABLE ASSY XA02

13-56 J9080084A X AXIS -LIMIT CABLE ASSY XA03

13-57 J9080085A X HOME SENSOR CABLE ASSY XA04

13-58 J9080086A Y AXIS ORIGIN CABLE ASSY YA01

13-59 J9080087A Y AXIS SENSOR CABLE ASSY YA02

13-60 J9080088A AXIS SENSOR CABLE ASSY YA03

13-60 J9080089A Y SUB BOARD POWER CABLE ASSY YA04

13-61 J9061367C FIDUCIAL CAMERA CABLE ASSY MK-VIS03

13-61 J9080090B HEAD CAMERA POWER CABLE ASSY VIS01

13-62 J9061371B FIX CAMERA I/F CABLE ASS'Y MK-VIS04

13-62 J9080091A CAMERA MUX CABLE ASSY VIS02

13-63 J9080101A X MOTOR PWR CABLE ASSY MD01

13-64 J9080102B X MOTOR ENC CABLE ASSY MD02

13-64 J9080103A X MOTOR CABLE ASS'Y MD03

13-65 J9080104A Y MOTOR PWR CABLE ASSY MD04

13-65 J9080105A Y MOTOR ENC CABLE ASS'Y MD05

13-66 J9080106A Y MOTOR CABLE ASSY MD06

13-66 J9080108A Z123 MOTOR PWR CABLE ASSY MD08

13-67 J9080109A Z123 MOTOR ENC CABLE ASSY MD09

13-67 J9080110A Z1 MOTOR CABLE ASS'Y MD10

13-68 J9080113B Z456 MOTOR PWR CABLE ASSY MD11

13-69 J9080114A Z456 MOTOR ENC CABLE ASSY MD12

13-69 J9080115A Z4 MOTOR CABLE ASS'Y MD13

13-70 J9080118A S MOTOR PWR CABLE ASSY MD14

13-71 J9080119A S MOTOR ENC CABLE ASSY MD15

Page Code Discription Specification Remark

13-71 J9080120A SWING MOTOR CABLE ASS'Y MD16P

13-72 J9080121A W MOTOR PWR CABLE ASSY MD17

13-72 J9080122A W MOTOR ENC CABLE ASSY MD18

13-72 J9080123A WIDTH MOTOR CABLE ASS'Y MD19P

13-73 J9080132A AUX IF CABLE ASSY CV32

13-74 J9080250A TOWER LAMP CABLE ASSY CV04

13-75 J9080321A FIX CAM PANEL CABLE ASSY VIS05

13-76 J9080423B SWITCH CABLE ASSY CV17

13-77 J9061222C HEAD ILL CABLE ASS'Y MK-HI02

13-77 J9061910A FIDUCIAL LED CABLE ASS'Y MK-HI03

13-78 J9061438B FLYING VISION DATA CABLE ASS'Y J9061438B(VIS07)

13-79 J9080062B FRONT LAMP CABLE ASSY CV03

13-80 J9080421B DOOR SWICH CABLE ASSY CV19

13-81 J9080068A LAMP SWITCH CABLE ASSY CV31

13-82 J9061328B CAN BUS CABLE ASS'Y MK-CA06

13-83 J9080095A CONV SENSOR CABLE ASS'Y CV11

13-84 J9080094A CONV SENSOR CABLE ASS'Y CV10

13-85 J9061208B CONV VACUUM CABLE ASS'Y HD02

13-85 J9061209B CONV ILL UP/DN SOL CABLE ASS'Y HD03

13-86 J9061212D SIDE ILL U/D SENSOR CABLE ASS'Y HD06

13-86 J9061213C HEAD SENSOR CABLE ASS'Y HD07

13-87 J9061214C HEAD SENSOR CABLE ASS'Y HD08

13-87 J9061215C HEAD SENSOR CABLE ASS'Y HD09

13-88 J9061216B HEAD SENSOR CABLE ASS'Y HD10

13-88 J9061217B HEAD SENSOR CABLE ASS'Y HD11

13-88 J9061218B HEAD SENSOR CABLE ASS'Y HD12

13-89 J9061768C THETA ORG SENSOR CABLE ASS'Y HD15
