Page Code Discription Specification Remark

13-71 J9080120A SWING MOTOR CABLE ASS'Y MD16P

13-72 J9080121A W MOTOR PWR CABLE ASSY MD17

13-72 J9080122A W MOTOR ENC CABLE ASSY MD18

13-72 J9080123A WIDTH MOTOR CABLE ASS'Y MD19P

13-73 J9080132A AUX IF CABLE ASSY CV32

13-74 J9080250A TOWER LAMP CABLE ASSY CV04

13-75 J9080321A FIX CAM PANEL CABLE ASSY VIS05

13-76 J9080423B SWITCH CABLE ASSY CV17

13-77 J9061222C HEAD ILL CABLE ASS'Y MK-HI02

13-77 J9061910A FIDUCIAL LED CABLE ASS'Y MK-HI03

13-78 J9061438B FLYING VISION DATA CABLE ASS'Y J9061438B(VIS07)

13-79 J9080062B FRONT LAMP CABLE ASSY CV03

13-80 J9080421B DOOR SWICH CABLE ASSY CV19

13-81 J9080068A LAMP SWITCH CABLE ASSY CV31

13-82 J9061328B CAN BUS CABLE ASS'Y MK-CA06

13-83 J9080095A CONV SENSOR CABLE ASS'Y CV11

13-84 J9080094A CONV SENSOR CABLE ASS'Y CV10

13-85 J9061208B CONV VACUUM CABLE ASS'Y HD02

13-85 J9061209B CONV ILL UP/DN SOL CABLE ASS'Y HD03

13-86 J9061212D SIDE ILL U/D SENSOR CABLE ASS'Y HD06

13-86 J9061213C HEAD SENSOR CABLE ASS'Y HD07

13-87 J9061214C HEAD SENSOR CABLE ASS'Y HD08

13-87 J9061215C HEAD SENSOR CABLE ASS'Y HD09

13-88 J9061216B HEAD SENSOR CABLE ASS'Y HD10

13-88 J9061217B HEAD SENSOR CABLE ASS'Y HD11

13-88 J9061218B HEAD SENSOR CABLE ASS'Y HD12

13-89 J9061768C THETA ORG SENSOR CABLE ASS'Y HD15
