xvii
Safety instructions
3.3 Caution labels
3.3.1 Effects on human body
Potential
hazard
Burn hazard
To avoid
hazard
Heater becomes very hot during and shortly after operation, so do not touch it.
Applicable
machines
YSH20 machines equipped with heater (option)
Case
• Setup
• Maintenance
Potential
hazard
Electrical shock hazard
To avoid
hazard
Do not touch while power is supplied.
Applicable
machines
All YS series machines (controller unit) except for inspection
equipment
Case
Maintenance
Potential
hazard
Loss of eyesight
To avoid
hazard
Do not directly look into laser beam.
Applicable
machines
IT options such as barcode readers (Class 2 laser)
YS series machines (Class 1 laser)
Case
All case
xviii
Safety instructions
Potential
hazard
Electrical shock
To avoid
hazard
Keep the ionizer away from eyes. Do not disassemble or touch the discharge needles.
Applicable
machines
Machines equipped with ionizer (option)
Case
All case
Potential
hazard
Electrical shock
To avoid
hazard
Always turn off UPS switch when performing maintenance work.
Applicable
machines
Machines equipped with UPS (option)
Case
Maintenance
Potential
hazard
Electrical shock
To avoid
hazard
Always turn off UPS switch when performing maintenance work.
Applicable
machines
Machines equipped with UPS (option)
Case
Maintenance
xix
Safety instructions
3.3.2 Machine damage
Potential
hazard
Adverse effects on component mounting accuracy
To avoid
hazard
Do not touch camera unit or apply impacts to it.
Applicable
machines
All machines
Case
• Setup
• Maintenance
Potential
hazard
Risk of damage
To avoid
hazard
Remove shipping bolts and clamps before using machine.
Applicable
machines
Feeder exchange carriage (option)
Case
Installation
Potential
hazard
Machine damage or malfunction
To avoid
hazard
Connect power only at the specified voltage.
Applicable
machines
All machines
Case
Installation
Example for machines that must be connected to 200 VAC
