xxii
Safety instructions
3.4 Label positions
The following warning/caution labels are attached to the YAMAHA products to ensure safe and correct use.
Check that the information on each label is clearly legible and comply with the instructions.
For safety precautions other than those on the labels shown in this section, see the instructions in "1. Safety".
n
NOTE
Basically, labels are attached to the positions shown below, although they may differ slightly depending on the
machine model.
n
NOTE
When connecting power to this equipment, refer to "Power connection terminals" described in the appendix of the
maintenance manual or user's manual.
Warning/caution labels
Front 1
N Open/close cover (front and rear sides)
N Open/close cover inner side
(front and rear sides)
N Open/close cover
(front and rear sides)
NMain switch
N Cutter inner side
N Cutter section
N Conveyor opening
(front and rear sides, right and
left sides)
93201-L4-10
xxiii
Safety instructions
n
Label positions
Warning/caution labels
Front 2
N X axis frame section inner side (front and rear sides)
N Feeder setup section
(2 locations each on front and rear sides)
N Right and left sides
N Lower panels
(front and rear sides)
N Panel inner side
93202-L4-10
xxiv
Safety instructions
n
Label positions
Warning/caution labels
Rear (YS24X+sATSII)
N Open/close cover
N Open/close cover
N Cutter section
N Cutter inner side
93203-L4-10
