Vision Teach Station User Manual 7 Software 10/2015 Edition 7.1 Supported SIPLACE Pro versions 141 7.1 Supported SIPLACE Pro versions At present, the vision teach station supports the following SIPLACE Pro versions: Soft…
7 Software Vision Teach Station User Manual
6.1 Vision teach station upgrade 10/2015 Edition
140
7 Software
NOTE 7
When we supply a vision teach station, the software is already fully installed on the computer.
The computer can be started up and used immediately. All the CD-ROMs needed for the installa-
tion are supplied as standard.
CAUTION 7
As of the 5.0.1 version, the vision teach station software additionally supports Windows 7, 32-bit
and 64-bit. Please note, that the old CAN card with the green CAN3 plug (item no. 03052590-xx)
does NOT support 64-bit operating systems! For this the new PowerCAN-II CAN card
(item no. 03079973-xx) is required .
Vision Teach Station User Manual 7 Software
10/2015 Edition 7.1 Supported SIPLACE Pro versions
141
7.1 Supported SIPLACE Pro versions
At present, the vision teach station supports the following SIPLACE Pro versions:
Software
Vision Teach Station
SIPLACE Pro Upgrade kit required
V 1.7 V 3.1
Vision teach station upgrade kit for
SIPLACE Pro (V3.1 SP1), item no. 00376902-01
V 2.2 V 4.1
Vision teach station upgrade kit for
SIPLACE Pro (V4.1 SP1), item no. 00385200-01
V 3.51 V 5.0 SP1
Vision teach station upgrade kit for
SIPLACE Pro (V5.0 SP1), item no. 00387300-01
V 3.51 V 5.2 SPx
Vision teach station upgrade kit for
SIPLACE Pro (V5.2 SPx), item no. 00388211-01
V4.1.1
V5.0 SP1 to
V7.x
Installation Package Vision Teach Station for
SIPLACE Pro 5.0SP1 to V7.x), item no. 00388350-xx
*)
V4.2.1
V5.0 SP1 to
V8.x
Installation Package Vision Teach Station for
SIPLACE Pro 5.0SP1 to V8.x), item no. 00388618-xx
**)
V4.3.1
V5.0 SP1 to
V9.x
Installation Package Vision Teach Station for
SIPLACE Pro V9.x), item no. 00388749-xx***)
V5.0.1
V5.0 SP1 to
V10.x
Installation Package Vision Teach Station for
SIPLACE Pro V10.X, item no. 00388779-xx****)
V5.0.2
V5.0 SP1 to
V10.x
Installation Package Vision Teach Station for
SIPLACE Pro V10.X, item no. 00388779-xx****)
V5.1.1
V5.0 SP1 to
V1
1.x
Installation Package Vision Teach Station for
SIPLACE Pro V11.X, item no. 00388779-xx*****)
V5.1.2
V5.0 SP1 to
V1
1.x
Installation Package Vision Teach Station for
SIPLACE Pro V11.X, item no. 00388779-xx*****)
V5.2.1
V5.0 SP1 to
V12.x
Installation Package Vision Teach Station for
SIPLACE Pro V12.X, item no. 00117256-xx******)
V5.2.2
V5.0 SP1 to
V12.x
Installation Package Vision Teach Station for
SIPLACE Pro V12.X, item no. 00117256-xx******)
V5.3.1
V5.0 SP1 to
V13.x
Installation Package Vision Teach Station for
SIPLACE Pro V13.X, item no. 00117257-xx*******)
7
Tab. 7.1 - 1 Currently supported SIPLACE Pro versions
*) The installation CD für SIPLACE Pro 7.0 is included in the package
**) The installation CD für SIPLACE Pro 8.0 is included in the package
***) The installation CD für SIPLACE Pro 9.x is included in the package
****) The installation CD für SIPLACE Pro 10.x is included in the package
*****) The installation CD für SIPLACE Pro 11.x is included in the package
*******) The installation CD für SIPLACE Pro 12.x is included in the package
********) The installation CD für SIPLACE Pro 13.x is included in the package
7 Software Vision Teach Station User Manual
7.2 Software upgrade 10/2015 Edition
142
7.2 Software upgrade
NOTE
From version VTS 3.51 / SIPLACE Pro 5.0 SP1 onwards it is possible to run the VTS on the
SIPLACE LAN, and thus access other SIPLACE Pro databases (version 5.0 SP1). If you want
to use this feature, you will have to reinstall the computer to ensure that the host name and IP
address are unique (see section 7.3, page 149). 7
Please also read sections 9.3 and 9.4 from page 165.
CAUTION: 7
Following items are important for the older software packages 00376902, 00385200 and
00387300:
When you install the software, make sure that the version of SIPLACE Pro matches the vision
teach station software (as shown in table 7.1 - 1 on page 141). The install routine does not check
the versions.
You should therefore check which versions of the software packages are installed before star-
ting the installation.
Carry out the installation in the order described below.
NOTE 7
As of Vision Teach Station version 4.1.1 you can update the Vision Teach Software independently
of the SIPLACE Pro version, if at least SIPLACE Pro V5.05SP1 is installed.
Please note that some of the new features (see section 7.5 on page 153) are only available with
SIPLACE Pro V7.0 or higher.
For this, simply deinstall the Vision Teach Station software as described in the last item in
section 7.2.3 on page 143.
Then install the new Vision Teach Station version as described in section 7.2.4.4 on page 148.
NOTE 7
To install or remove the software you will need access with administrator rights
You will find the latest information on the setup CD and in the "ReadMe.txt" file.
