50
Technical Data
Transport and Delivery Configuration
Description
Within Europe, the machine
is delivered on a robust
wooden pallet. If sent over-
seas, the machine is pack-
aged in a wooden crate.
Configuration when
delivered
• The extension kit on the
PCB input side with the
computer unit or the box
PC are disconnected from
the basic machine.
• All electrical cables to the
basic machine are discon-
nected.
• The conveyor track on the
single conveyor is set to a
width of 210 mm. On the
dual conveyor, the default
width of track 1 is 100mm
and of track 2 is 210 mm.
• The input conveyors of the
single and dual conveyor
are dismantled. The elec-
trical cables to the convey-
or motors and light barriers
are disconnected.
• Both keyboards and the
monitors are disconnect-
ed.
• The main fault indicator is
dismantled.
Transport dimensions and weight
Means of transport
A fork-lift truck with the following specification will be needed
to carry the machine in its crate:
Length
Width
Height
2404 mm
2790 mm
1600 mm
Weight Dispatch Dispatch
within Europe overseas
3980 kg 4420 kg
Fork length
Lifting power
Clear fork width
min. 1800 mm
min. 6000 kg
min. 350 mm
Engagement point
for the fork-lift
Engagement point
for the fork-lift
51
Standard List
The following functions are included with the SIPLACE D3 as standard at no additional cost:
SIPLACE D3 standard features
Vacuum sensor X
Force measurement X
Force sensor X
Fiducial & ink spot recognition X
Nozzle changers for the TwinHead X
Set of TwinHead nozzles X
Set of standard nozzles per head X
Service box X
Single conveyor, stationary side right X
Single conveyor, stationary side left X
Wide board configuration X
PCB buffer function on conveyor X
PCB stopper laser light barrier X
Automatic electrical width adjustment X
Operation on both sides X
LCD monitors X
Touch-screen monitor X
Indicator lamp X
Tape cutter with reject bin X
Tape separating plates X
Magnetic pin support X
52
List of Options
Options for the SIPLACE D3
Transport height (900, 930, 950) X
Flexible dual conveyor, fixed side right X
Flexible dual conveyor, fixed side left X
PCB alignment, single conveyor X
PCB alignment, dual conveyor X
Long board option, single conveyor X
Long board option, dual conveyor X
PCB barcode scanner, 1D X Restrictions for a PCB longer than 430 mm
PCB barcode scanner, 2D X Restrictions for a PCB longer than 430 mm
Head reconfiguration kits X
12-nozzle Collect&Place head X
High-resolution camera, type 29 (for C&P12) X
Component sensor, C&P12 X
0201 package X
6-nozzle Collect&Place head X
TwinHead X
High-Force Head X
Stationary camera P&P, type 25, 16 x 16, digital X For the TwinHead only
Coplanarity module X For the TwinHead only (at location 3)
Nozzle changer (according to the head) X
Nozzle changer, 2nd row (depends on head) X
Reject bin sensor X
SIPLACE component changeover table X
Dip module X
External power supply for the CO table X
Compressed air distributor for bulk case feeder
modules
X
Tape reel holder, 3 x 8 mm feeder module, V2 X
Tape reel holder adapter plate X
Feeder module cover flap X
Feeder module fixing X
Splice detection X
Waffle-pack tray holder X Can be used at locations 2 and 4
Setup center X
110/208 V conversion kit X
Vacuum pump X Not possible on the TwinHead
SIPLACE matrix tray changer (MTC) X At locations 2 and 4
SIPLACE waffle-pack changer (WPC) X At location 2
Productivity lift X Max. PCB width: single track 460 mm
double track 216 mm
Max. CO height: 17 mm on the underfloor
section
