1.106 User Manual Software Version 07SP04
operations:
Clean After The automatic screen clean after downtime process chosen in the above menu
parameter is carried out after a countdown of the number of minutes set in this
parameter.
Dry Clean Speed This parameter sets the speed of the screen clean dry wipe for optimization.
Wet Clean Speed This parameter sets the speed of the screen clean wet wipe for optimization.
Vac Clean Speed This parameter sets the speed of the screen clean vacuum for optimization.
Front Start Offset
(Blue USC)
This parameter determines the distance from the front edge of the board that
the cleaning stroke must start.
Rear Start Offset
(Blue USC)
This parameter determines the distance from the rear edge of the board that
cleaning must complete.
Vortex Cassette
Life
This parameter sets the number of cleaning strokes that are applied before a
cleaning cassette is replaced.
Cleaning Operation Note
Wet A warning is given if the end stroke is wet.
Dry
Vac
None
Minimum Maximum Increment
5.0 mins 120.0 mins 1.0 min
Minimum Maximum Increment
10.0mm/sec 120.0mm/sec 1.0mm/sec steps
Minimum Maximum Increment
10.0mm/sec 100.0mm/sec 1.0mm/sec steps
Minimum Maximum Increment
10.0mm/sec 100.0mm/sec 1.0mm/sec steps
Minimum Maximum Increment
0.0mm 60.0mm 1.0mm
Minimum Maximum Increment
0.0mm 60.0mm 1.0mm
Minimum Maximum Increment Default
0.0 200.0 1.0 20.0
0$&+,1(352*5$00,1*
0(183$5$0(7(56
Software Version 07SP04 User Manual 1.107
Vortex Clean Rate This parameter sets the frequency (in print cycles) at which screen cleaning
occurs.
Vortex Solvent
Rate
This parameter sets the frequency (in cleaning cycles) at which solvent is
dispensed.
Vortex Vac Start The distance, in from the front edge of the board, where vacuum is applied.
Vortex Vac Stop The distance, in from the front edge of the board, where vacuum application is
stopped.
Vortex Vacuum
Rate
This parameter sets the frequency (in cleaning cycles) at which vacuum is
applied.
Vaccum On Period This parameter sets the period for which vacuum is applied.
Front Start Offset
(Vortex USC)
This parameter determines the distance from the front edge of the board that
the cleaning stroke must finish.
Rear Start Offset
(Vortex USC)
This parameter determines the distance from the rear edge of the board that
cleaning must start.
Stop After Idle This parameter when enabled sets the time the product is held in contact with
Minimum Maximum Increment Default
0.0 200.0 1.0 0.0
Minimum Maximum Increment Default
1.0 10.0 1.0 1.0
Minimum Maximum Increment Default
Vacuum Stop Board Width 1.0 0.0
Minimum Maximum Increment Default
-100.0mm Vacuum Stop 1.0mm 0.0mm
Minimum Maximum Increment Default
1.0 10.0 1.0 1.0
Minimum Maximum Increment Default
0.0 sec 10.0 secs 1.0 sec 5.0 secs
Minimum Maximum Increment Default
-60.0mm 60.0mm 1.0mm 30.0mm
Minimum Maximum Increment Default
-60.0mm 60.0mm 1.0mm 30.0mm
0$&+,1(352*5$00,1*
0(183$5$0(7(56
1.108 User Manual Software Version 07SP04
the stencil until both upline and downline systems are ready to transfer.
Front Knead Speed This parameter sets the speed of kneading in the forward direction.
NOTE
While Fast Print Speed is licensed and enabled the maximum speed is 300mm/
sec. This parameter is not available while ProFlow is fitted.
Rear Knead Speed This parameter sets the speed of kneading in the rearward direction.
NOTE
While Fast Print Speed is licensed and enabled the maximum speed is 300mm/
sec. This parameter is not available while ProFlow is fitted.
Front Knead
Pressure
This parameter sets the pressure to be applied, while using squeegees, when
kneading in the forward direction.
Rear Knead
Pressure
This parameter sets the pressure to be applied, while using squeegees, when
kneading in the rearward direction.
Board 1 Fiducial
Type
This determines the type of model to be used for this fiducial. Options are:
Minimum Maximum Increment
0.0 mins 200.0 mins 1.0 min
Minimum Maximum Increment Default
2.0mm/sec 150.0mm/sec 1.0mm/sec 10.0mm/sec
Minimum Maximum Increment Default
2.0mm/sec 150.0mm/sec 1.0mm/sec 10.0mm/sec
Minimum Maximum Increment Default
0.0Kg 20.0Kg 0.2Kg 5.0Kg
Minimum Maximum Increment Default
0.0Kg 20.0Kg 0.2Kg 5.0Kg
Model Option Note
Circle
See vision system
Rectangle
Diamond
Triangle
Double Square
Cross
Video Model
