Factors As an aid to fault diagnosis a facility exists to enable the user to extract the
relevant SPC output data to the READINGS.DEK file and to analyze this file
within the QC-Cal program. Filter files are setup in the QC-Cal program using
factors by the user to filter the SPC output data. The following table defines
these factors:
Factor Definition
Factor 1 Squeegee - denotes which squeegee was used:
0 - No Squeegees
1 - Front Squeegee
2 - Rear Squeegee
3 - Front and Rear Squeegees
Factor 2 Batch Count - Identifies the current batch count
Factor 3 2D Inspection - Denotes which type of 2D inspection was used to
generate the 2D SPC data:
0 - No Inspection carried out
1 - Stencil Inspection
2 - Board Inspection
3 - Stencil and Board Inspection
Factor 4 Alignment Inspection - Denotes which type of alignment inspection was
used to generate the alignment error SPC data:
0 - No alignment inspection
1 - Pre-print alignment inspection
2 - Pre and Post-print alignment inspection
3 - Post-print alignment inspection
Factor 5 Offset - Indicates the application of a change in print offsets to the current
product file:
None - No offset change
Fx - Forward X offset change
Fy - Forward Y offset change
Ft - Forward Theta offset change
Rx - Reverse X offset change
Ry - Reverse Y offset change
Rt - Reverse Theta offset change
Factor 6 Product Barcode - identifies the product barcode of the current product
which has been read by an external barcode reader. No barcode reader
setup is indicated by - NO_CODE
Factor 7 Machine ID - machine serial number
Factor 8 Machine location - indicates customer line number, location or site
Factor 9 Stencil Barcode - identifies the stencil barcode of the current stencil
which has been read by a stencil barcode reader. No barcode reader
setup is indicated by - NO_CODE
Factor 10 Machine Software Version - identifies the current machine software
version
Factor 11 Forward Offset - denotes the current forward offset settings of the
machine, in the form: ‘x:y:theta’
Factor 12 Rear Offset - denotes the current rear offset settings of the machine, in
the form ‘x:y:theta’
0$&+,1(352*5$00,1*
63&&21),*85$7,21
Software Version 07SP04 User Manual 1.123
Edit SPC Limits Pressing the Edit Limits key when SPC Configuration Page is displayed opens
the following window and menu bar:
NOTE
The shaded parameters in the window are set by the machine.
Each parameter can be set to stop the machine if the limits are exceeded.
The Left and Right keys move the cursor across the parameter columns.
The Next and Previous keys move the cursor vertically through the parameter
list.
The Incr. and Decr. keys increase or decrease the highlighted parameter.
The Exit key returns to the previous menu.
The SPC parameters and their edit limits are listed in the table below:
EDIT SPC LIMITS
X Alignment Deviation
Y Alignment Deviation
Theta Alignment Deviation
Board Stretch
Front Pressure
Rear Pressure
Separation Speed
Temperature
Relative Humidity
Cycle Time
Table Position
Board Fiducial 1 Score
Parameter Stop On
Limit
Maximum
Limit
Minimum
Limit
Nominal
+0.025
+0.025
+27
+0.10
+0.2
+2.00
+2.00
+5
+25
+2.0
+0.4
+300
-0.025
-0.025
-27
-0.10
-0.2
-2.00
-2.00
-5
-25
-2.0
-0.4
-200
0.000
0.000
0
0.00
0.0
0.0
1.0
22
50
30.0
0.000
700
NO
NO
NO
NO
NO
NO
NO
NO
NO
NO
NO
NO
Left Right Next Previous Incr. Decr. Exit
Parameter Nominal Default
Tolerances
Increment
Size
Tolerance
Range
X Alignment Deviation 0 ± 0.025mm 0.0005mm ± 1mm
Y Alignment Deviation 0 ± 0.025mm 0.0005mm ± 1mm
Theta Alignment Deviation 0 ± 31 arcsec 1 arcsec ± 100arcsec
Board Stretch 0 ± 0.1mm 0.01mm ± 1mm
Front pressure Product
Parameter
± 0.2kg 0.01kg ± 2kg
Rear Pressure Product
Parameter
± 0.2kg 0.01kg ± 2kg
Separation Speed Product
Parameter
± 0.5mm 0.25mm ± 5mm
Temperature 22 ± 5 degrees 1 degree ± 10 degrees
Relative Humidity 50 ± 25% 1% ± 50%
Cycle Time 30 ± 2 secs 0.1 sec ± 10 secs
Table Position Product
Parameter
(print gap)
± 0.2mm 0.025mm ± 1mm
0$&+,1(352*5$00,1*
63&&21),*85$7,21
1.124 User Manual Software Version 07SP04
Board Fiducial 1 Score 700 +375, +100 10 ± 500
Screen Fiducial 1 Score 700 +375, +100 10 ± 500
Board Fiducial 2 Score 700 +375, +100 10 ± 500
Screen Fiducial 2 Score 700 +375, +100 10 ± 500
Board Fiducial 3 Score 700 +375, +100 10 ± 500
Screen Fiducial 3 Score 700 +375, +100 10 ± 500
X Pre Alignment Deviation 0 ± 0.025mm 0.0005mm ± 1mm
Y Pre Alignment Deviation 0 ± 0.025mm 0.0005mm ± 1mm
Theta Pre Align Deviation 0 ± 27 arcsec 1 arcsec ± 100 arcsec
Pre Print Board Stretch 0 ± 0.1mm 0.01mm ± 1mm
Pre Fid 1 X Align Deviation 0 ± 0.0625mm 0.0005mm ± 1mm
Post Fid 1 X Align Deviation 0 ± 0.0625mm 0.0005mm ± 1mm
Pre Fid 1 Y Align Deviation 0 ± 0.0625mm 0.0005mm ± 1mm
Post Fid 1 Y Align Deviation 0 ± 0.0625mm 0.0005mm ± 1mm
Pre Fid 2 X Align Deviation 0 ± 0.0625mm 0.0005mm ± 1mm
Post Fid 2 X Align Deviation 0 ± 0.0625mm 0.0005mm ± 1mm
Pre Fid 2 Y Align Deviation 0 ± 0.0625mm 0.0005mm ± 1mm
Post Fid 2 Y Align Deviation 0 ± 0.0625mm 0.0005mm ± 1mm
Pre Fid 3 X Align Deviation 0 ± 0.0625mm 0.0005mm ± 1mm
Post Fid 3 X Align Deviation 0 ± 0.0625mm 0.0005mm ± 1mm
Pre Fid 3 Y Align Deviation 0 ± 0.0625mm 0.0005mm ± 1mm
Post Fid 3 Y Align Deviation 0 ± 0.0625mm 0.0005mm ± 1mm
Front X Act Rel Movement 0 ± 0.45mm 0.025mm ± 2mm
Rear X Act Rel Movement 0 ± 0.85mm 0.025mm ± 2mm
Act Y Rel Movement 0 ± 0.25mm 0.025mm ± 2mm
Front X Act Position Front X Rough
Align Value
± 0.45mm 0.025mm ± 9mm
Rear X Act Position Rear X Rough
Align Value
± 0.85mm 0.025mm ± 9mm
Act Y Position Y Rough Align
Value
± 0.25mm 0.025mm ± 9mm
PVP Result 80 ± 20% 5% ± 50%
Front Print Speed Product
Parameter
± 0.5mm 0.25mm ± 5mm
Rear Print Speed Product
Parameter
± 0.5mm 0.25mm ± 5mm
Parameter Nominal Default
Tolerances
Increment
Size
Tolerance
Range
