1.90 User Manual Software Version 07SP04
19.Repeat Steps 5-18 for the other squeegee.
20.The printer operates continuously. The menu bar displays the following
options, these may be selected at any time during a print run:
End Run Selecting this option stops the printer on completion of the current print cycle.
Stop Cycle Selecting this option stops the printer immediately, halting all actions.
Paste Load Selecting this option allows the operator to load paste to the stencil either
manually or automatically.
Clean Screen Selecting this option allows the operator to clean the stencil in addition to the
programmed cleaning intervals.
Adjust Selecting this option allows the operator to adjust any of the main process
parameters displayed on the pop-up menu without having to access the main
menu or stop the machine.
The machine continues to run using the existing values, when Exit (F8) is
selected the new values are used.
To save the new values, select Setup (F6), select Edit Data (F3), select Save
(F2), select Exit (F8).
Knead Paste Selecting this option runs the knead paste process in addition to the pro-
grammed cleaning intervals.
Adjust Inspect Selecting this option allows the operator to edit 2D inspection parameters.
NOTE
Global Limits, Limit Sets and Site parameters can be edited. Site coordinates
can not be adjusted. Any changes made to inspection parameters are saved
on exit.
End
Run
Stop
Cycle
Paste
Load
Clean
Screen
Adjust
Knead
Paste
Adjust
Inspect
0$&+,1(352*5$00,1*
0(183$5$0(7(56
Software Version 07SP04 User Manual 1.91
MENU PARAMETERS
Each product has a set of parameters which are unique to that particular product
and which need to be setup to obtain acceptable printing results. These
parameters are listed below with a definition of each as an aid to machine setup.
Product Name The file name for the particular product. The name can consist of up to 68
alphanumeric characters with no punctuation.
Product ID The product ID is a parameter that allows a description of the product. This
string may be up to 32 characters long, but only the first 20 characters are
displayed.
Dwell Height The parameter allows the user to set the squeegee dwell height. Setting of a
lower height helps the media to stay evenly spread across the length of the
squeegee when a less viscous media is used. Setting a high height allows
viewing of the paste roll.
Dwell Speed This preference adjusts the speed at which the squeegee moves to dwell height.
A slower speed helps to reduce the spreading of a less viscous media, ie flux.
It should be noted that decreasing this speed causes the cycle time to increase.
Image Detail This parameter allows the user to modify the stencil image data of the selected
screen library file. Once selected, pressing Incr. or Decr. Keys opens the Image
Detail Configuration page.
NOTE
This parameter is only displayed, if Screen Size in Set Preferences has been
selected to Screen Library.
Once selected, pressing Incr. or Decr. Keys opens the following Image Detail
Configuration page:
Mesh Front This parameter sets the distance between the inner edge of the stencil frame
Minimum Maximum Increment Default
5.0mm 40.0mm 1.0mm 30.0mm
Minimum Maximum Increment Default
10.0mm/sec 30.0mm/sec 1.0mm/sec 24.0mm/sec
SCREEN TYPE
MESH FRONT
MESH REAR
MESH LEFT
MESH RIGHT
X JUSTIFICATION
Y JUSTIFICATION
IMAGE X
IMAGE Y
BARCODE Y
265
38.0
38.0
38.0
38.0
CENTRE
CENTRE
330.4
330.4
97.0
mm
mm
mm
mm
38.0
mm
mm
mm
Image Detail Configuration
0$&+,1(352*5$00,1*
0(183$5$0(7(56
1.92 User Manual Software Version 07SP04
and the stencil glue line at the front of the frame. It defines the area that should
not be contacted by the squeegees/ProFlow.
Mesh Rear This parameter sets the distance between the inner edge of the stencil frame
and the stencil glue line at the rear of the frame. It defines the area that should
not be contacted by the squeegees/ProFlow.
Mesh Left This parameter sets the distance between the inner edge of the stencil frame
and the stencil glue line at the left of the frame. It defines the area that should
not be contacted by the squeegees/ProFlow.
Mesh Right This parameter sets the distance between the inner edge of the stencil frame
and the stencil glue line at the right of the frame. It defines the area that should
not be contacted by the squeegees/ProFlow.
X Justification This parameter defines the position of the image about the Image X parameter.
The image can be left, right or centre justified about Image X. Options are:
Y Justification This parameter defines the position of the image about the Image Y parameter.
The image can be front, rear or centre justified about Image Y. Options are:
Image X This parameter defines the dimension in the X axis from the right inner edge of
the stencil frame to either:
Right hand edge of the image - right justified image
Left hand edge of the image - left justified image
Minimum Maximum Increment Default
0.0mm Stencil Length - 250.0mm 0.1mm 38.0mm
Minimum Maximum Increment Default
0.0mm Stencil Length - 250.0mm 0.1mm 38.0mm
Minimum Maximum Increment Default
0.0mm Stencil Width - 250.0mm 0.1mm 38.0mm
Minimum Maximum Increment Default
0.0mm Stencil Width - 250.0mm 0.1mm 38.0mm
Option Default
Left Centre
Right
Centre
Option Default
Front Centre
Rear
Centre
