Software Version 07SP04 User Manual 1.95
stencil type selected.
NOTE
With the remote board stop fitted the minimum is 119mm and the maximum is
508.5mm.
Board Length This parameter is used to set the default values for the board stop position in
the X direction, the paste dispensing area and the AutoFlex reset columns. The
maximum value depends on the type of stencil selected.
NOTE
With the remote board stop fitted the minimum is 130mm and the maximum is
508mm. With the large board option the maximum is 620mm, although boards
of 644mm can be loaded.
Board Thickness This parameter is used by the machine to set correct vision and print heights.
Front Print Speed This parameter sets the speed across the stencil when printing.
NOTE
While Fast Print Speed is licensed and enabled the maximum speed is 300mm/
sec. If ProFlow is fitted this parameter is not available while Advanced ProFlow
is enabled. This is also the knead speed if ProFlow is fitted and Advanced
ProFlow is disabled.
Minimum Maximum Increment
50.0mm 265 508.0mm 0.1mm
255 432.0mm
249 330.0mm
Fuji 460.0mm
Sanyo 284.0mm
Heraeus 344.0mm
Minimum Maximum Increment
40.0mm 265 510.0mm 0.1mm
255 460.0mm
249 430.0mm
Fuji 460.0mm
Sanyo 420.0mm
Heraeus 344.0mm
Minimum Maximum Increment
0.20mm 6.00mm 0.1mm
Minimum Maximum Increment Default
2.0mm/sec 150.0mm/sec 1.0mm/sec 10.0mm/sec
0$&+,1(352*5$00,1*
0(183$5$0(7(56
1.96 User Manual Software Version 07SP04
Rear Print Speed This parameter sets the speed across the stencil when printing.
NOTE
While Fast Print Speed is licensed and enabled the maximum speed is 300mm/
sec. If ProFlow is fitted this parameter is not available while Advanced ProFlow
is enabled. This is also the knead speed if ProFlow is fitted and Advanced
ProFlow is disabled.
Flood Speed This Parameter sets the flood blade speed across the stencil when performing
a flood stroke.
NOTE
While Fast Print Speed is licensed and enabled the maximum speed is 300mm/
sec. This parameter is not available while ProFlow is fitted.
FWD Start Speed This parameter sets the start speed of the forward print stroke. The transition
between start and stop speeds is linear with repect to time.
NOTE
While Fast Print Speed is licensed and enabled the maximum speed is 300mm/
sec. This parameter is only available while ProFlow is fitted and Advanced
ProFlow is enabled. This is also the knead speed if ProFlow is fitted and
Advanced ProFlow is enabled.
FWD End Speed This parameter sets the end speed of the forward print stroke. The transition
between start and stop speeds is linear with repect to time.
NOTE
While Fast Print Speed is licensed and enabled the maximum speed is 300mm/
sec. This parameter is only available while ProFlow is fitted and Advanced
ProFlow is enabled. This is also the knead speed if ProFlow is fitted and
Advanced ProFlow is enabled.
RWD Start Speed This parameter sets the start speed of the rearward print stroke. The transition
between start and stop speeds is liear with repect to time.
Minimum Maximum Increment Default
2.0mm/sec 150.0mm/sec 1.0mm/sec 10.0mm/sec
Minimum Maximum Increment
10.0mm/sec 150.0mm/sec 1.0mm/sec
Minimum Maximum Increment Default
2.0mm/sec 150.0mm/sec 1.0mm/sec 100.0mm/sec
Minimum Maximum Increment Default
2.0mm/sec 150.0mm/sec 1.0mm/sec 100.0mm/sec
Minimum Maximum Increment Default
2.0mm/sec 150.0mm/sec 1.0mm/sec 100.0mm/sec
0$&+,1(352*5$00,1*
0(183$5$0(7(56
Software Version 07SP04 User Manual 1.97
NOTE
While Fast Print Speed is licensed and enabled the maximum speed is 300mm/
sec. This parameter is only available while ProFlow is fitted and Advanced
ProFlow is enabled. This is also the knead speed if ProFlow is fitted and
Advanced ProFlow is enabled.
RWD End Speed This parameter sets the end speed of the rearward print stroke. The transition
between start and stop speeds is linear with repect to time.
NOTE
While Fast Print Speed is licensed and enabled the maximum speed is 300mm/
sec. This parameter is only available while ProFlow is fitted and Advanced
ProFlow is enabled. This is also the knead speed if ProFlow is fitted and
Advanced ProFlow is enabled.
Print Front Limit This determines the distance from the front edge of the board that printing must
start.
NOTE
With Paste Trails enabled or ProFlow fitted the minimum value is 0mm.
Print Rear Limit This determines the distance from the rear edge of the board that printing must
start.
NOTE
With Paste Trails enabled or ProFlow fitted the minimum value is 0mm.
Front Pressure This parameter sets the force applied by the front squeegee during its print
stroke.
Rear Pressure This parameter sets the force applied by the rear squeegee during its print
stroke.
Flood Height This parameter sets the height of the flood blade above the stencil during a flood
Minimum Maximum Increment Default
2.0mm/sec 150.0mm/sec 1.0mm/sec 100.0mm/sec
Minimum Maximum Increment Default
-6.5mm Board Width - print rear limit 0.1mm 0.0mm
Minimum Maximum Increment Default
-6.5mm Board Width - print front limit 0.1mm 0.0mm
Minimum Maximum Increment
0.0Kg 20.0Kg 0.2Kg
Minimum Maximum Increment
0.0Kg 20.0Kg 0.2Kg
