0$&+,1(352*5$00,1*
0(183$5$0(7(56
1.96 User Manual Software Version 07SP04
Rear Print Speed This parameter sets the speed across the stencil when printing.
NOTE
While Fast Print Speed is licensed and enabled the maximum speed is 300mm/
sec. If ProFlow is fitted this parameter is not available while Advanced ProFlow
is enabled. This is also the knead speed if ProFlow is fitted and Advanced
ProFlow is disabled.
Flood Speed This Parameter sets the flood blade speed across the stencil when performing
a flood stroke.
NOTE
While Fast Print Speed is licensed and enabled the maximum speed is 300mm/
sec. This parameter is not available while ProFlow is fitted.
FWD Start Speed This parameter sets the start speed of the forward print stroke. The transition
between start and stop speeds is linear with repect to time.
NOTE
While Fast Print Speed is licensed and enabled the maximum speed is 300mm/
sec. This parameter is only available while ProFlow is fitted and Advanced
ProFlow is enabled. This is also the knead speed if ProFlow is fitted and
Advanced ProFlow is enabled.
FWD End Speed This parameter sets the end speed of the forward print stroke. The transition
between start and stop speeds is linear with repect to time.
NOTE
While Fast Print Speed is licensed and enabled the maximum speed is 300mm/
sec. This parameter is only available while ProFlow is fitted and Advanced
ProFlow is enabled. This is also the knead speed if ProFlow is fitted and
Advanced ProFlow is enabled.
RWD Start Speed This parameter sets the start speed of the rearward print stroke. The transition
between start and stop speeds is liear with repect to time.
Minimum Maximum Increment Default
2.0mm/sec 150.0mm/sec 1.0mm/sec 10.0mm/sec
Minimum Maximum Increment
10.0mm/sec 150.0mm/sec 1.0mm/sec
Minimum Maximum Increment Default
2.0mm/sec 150.0mm/sec 1.0mm/sec 100.0mm/sec
Minimum Maximum Increment Default
2.0mm/sec 150.0mm/sec 1.0mm/sec 100.0mm/sec
Minimum Maximum Increment Default
2.0mm/sec 150.0mm/sec 1.0mm/sec 100.0mm/sec
0$&+,1(352*5$00,1*
0(183$5$0(7(56
Software Version 07SP04 User Manual 1.97
NOTE
While Fast Print Speed is licensed and enabled the maximum speed is 300mm/
sec. This parameter is only available while ProFlow is fitted and Advanced
ProFlow is enabled. This is also the knead speed if ProFlow is fitted and
Advanced ProFlow is enabled.
RWD End Speed This parameter sets the end speed of the rearward print stroke. The transition
between start and stop speeds is linear with repect to time.
NOTE
While Fast Print Speed is licensed and enabled the maximum speed is 300mm/
sec. This parameter is only available while ProFlow is fitted and Advanced
ProFlow is enabled. This is also the knead speed if ProFlow is fitted and
Advanced ProFlow is enabled.
Print Front Limit This determines the distance from the front edge of the board that printing must
start.
NOTE
With Paste Trails enabled or ProFlow fitted the minimum value is 0mm.
Print Rear Limit This determines the distance from the rear edge of the board that printing must
start.
NOTE
With Paste Trails enabled or ProFlow fitted the minimum value is 0mm.
Front Pressure This parameter sets the force applied by the front squeegee during its print
stroke.
Rear Pressure This parameter sets the force applied by the rear squeegee during its print
stroke.
Flood Height This parameter sets the height of the flood blade above the stencil during a flood
Minimum Maximum Increment Default
2.0mm/sec 150.0mm/sec 1.0mm/sec 100.0mm/sec
Minimum Maximum Increment Default
-6.5mm Board Width - print rear limit 0.1mm 0.0mm
Minimum Maximum Increment Default
-6.5mm Board Width - print front limit 0.1mm 0.0mm
Minimum Maximum Increment
0.0Kg 20.0Kg 0.2Kg
Minimum Maximum Increment
0.0Kg 20.0Kg 0.2Kg
0$&+,1(352*5$00,1*
0(183$5$0(7(56
1.98 User Manual Software Version 07SP04
stroke.
Transfer Head Size This parameter specifies the size of the transfer head (distance between the
skis) fitted to the ProFlow unit. Options are:
Stencil Protection This parameter sets whether tooling to support the stencil, outside the board
and clamp envelopes, is in use. Options are:
NOTE
This parameter is only displayed while ProFlow is fitted. If Knead Off Image is
enabled, Stencil Protection must be switched Off. Stencil Protection when
enabled prevents the following:
• Knead Off Image
• Rising Table from going to Print Height without a board
• Rails from supporting the Transfer Head
System Pressure This is the amount of print pressure (downward force) applied onto the stencil
by the ProFlow unit.
Print Paste
Pressure
This is the pressure applied to paste in the ProFlow unit while kneading and
printing.
NOTE
Only available while ProFlow and the Software Controlled Air Regulator (SCAR)
are fitted and Advanced ProFlow is set to Disabled. This is also the default
Minimum Maximum Increment
0.0mm 5.0mm 0.02mm
Option Default
150mm 300mm
300mm
350mm
400mm
450mm
500mm
Options Available Default
On On
Off
Minimum Maximum Increment Default
0.0Kg 20.0Kg 0.2Kg 4.0Kg
Minimum Maximum Increment Default
0.0 bar 4.0 bar 0.2 bar 2.0 bar
