Page +$1:+$ 35 Docking C art (6/6) SM482 PLUS NO. P ART NO. P ART NAME Q'TY Old No. Applicable Equipment Reference AM03-001729A CAB LE ASSY -FRONT D-CART PWR CABLE ASSY 1 J9080852D LE FT FDR SOL OUTPUT CABLE ASSY , …
Page
+$1:+$
34
SM482
PLUS
Docking Cart (6/6)
Page
+$1:+$
35
Docking Cart (6/6)
SM482
PLUS
NO. PART NO. PART NAME Q'TY Old No. Applicable Equipment Reference
AM03-001729A CABLE ASSY-FRONT D-CART PWR CABLE ASSY 1
J9080852D LEFT FDR SOL OUTPUT CABLE ASSY, D-CART[S 1
J9080853B RIGHT FDR SOL OUTPUT CABLE ASSY, D-CART[ 1
J9080854C LEFT FDR SENOR INPUT CABLE ASSY, D-CART[ 1
J9080855B RIGHT FDR SENOR INPUT CABLE ASSY, D-CART 1
J9080857B FDR INPUT EXT CABLE ASSY, D-CART[SM_FD01 1
AM03-001739A CABLE ASSY-FEEDER CN7 EXT CABLE ASSY 1
AM03-013728A CABLE ASSY-ND-CART RY1 EXT 2 1
AM03-001730A CABLE ASSY-REAR D-CART PWR CABLE ASSY 1
Page
+$1:+$
36
SM482
PLUS
Backup Table Ass’y
