P-313-006_SIGMA_Series_Tape_Feeder - 第105页

– 99 – T ape F eeder GT -2 4 322 No. Part No. Part Name Qty . Detail Y amaha Hitachi 4A1 KYD-MC406-00 0926C30Y LEVER(SUP) 1 4A2 KYD-MC421-00 216F0914 PIN_GUIDE(SUP) 1 4A3 KYD-MC22K-00 222P0201 SPRING_TORSION 1 4A7 KYD-MC…

– 98 –

24,32mm

5 Suppressor Section

1710-006

See Fig.P-1

Key No.40

See Fig.P-1

Key No.1

See Fig.P-2

Key No.102

For 32mm

4B7

4A8

4A7

4A9

4B5

4A7

4B0

4A1

4A3

4A2

4B4

4B5

4A9

4B3

4A8

4B7

4B5

– 99 –

Tape Feeder GT-24322

No.

Part No.

Part Name Qty. Detail

Yamaha Hitachi

4A1 KYD-MC406-00 0926C30Y LEVER(SUP) 1

4A2 KYD-MC421-00 216F0914 PIN_GUIDE(SUP) 1

4A3 KYD-MC22K-00 222P0201 SPRING_TORSION 1

4A7 KYD-MC40N-00 0926C310 CHUTE 1

4A8 KYD-MC418-00 09262318 ASSY_PLATE(SUP) 1

4A9 KYD-MC22G-00 221D0196 MACHINE_SCREW 2 PAN M2L1.5

4B0 90990-02J023 221CA027 SCREW,SET 1 SET M4L4

4B3 KYD-MC404-00 0804000J NAME PLATE 1

4B4 KYD-MC22H-00 221H0230 WASHER 1

4B5 90167-02JA06 221DA103 MACHINE SCREW 3 FLT M2.5L6

4B7 90166-02JA06 221DA005 MACHINE SCREW 2 PAN M2.5L6

1710-006

– 100 –

24,32mm

1 Joint Detection Unit

1710-006

PD Joint Detection Unit DS-24322
