– 1 17 – T ape Feeder GT - 4 4 562 No. Part No. Part Name Qty . Detail Y amaha Hitachi 331 90166-02J208 221DA003 SCREW ,P AN HEAD 2 P AN M2L8 384 KYD-MC405-00 0926C20M BASE 1 385 KYD-MCN2H-00 023E0003 ASSY_GEAR 2 386 KYD…

100%1 / 170
– 116 –
44,56mm
Q
4 Cover Tape Winding Section
1710-006
See Fig.Q-1
Key No.1
3B4
386
3B3
3A1
3B1
3B1
3A2
3D9
3A4
3A4
3B8
3B8
3E1
3E1
331
3D4
3B0
3B9
3C0
3B7
3B6
391
3C4
394
396
397
398
399
3A0
3A9
384
3A3
392
3B0
3A6
3B5
389
395
3C1
3A9
393
390
387
388
3C2
385
385
3B2
3A7
3A8
3C5
– 117 –
Tape Feeder GT-44562
No.
Part No.
Part Name Qty. Detail
Yamaha Hitachi
331 90166-02J208 221DA003 SCREW,PAN HEAD 2 PAN M2L8
384 KYD-MC405-00 0926C20M BASE 1
385 KYD-MCN2H-00 023E0003 ASSY_GEAR 2
386 KYD-MC412-00 023E0036 ASSY_GEAR 2
387 KYD-MC60F-00 0926220G ASSY_GEAR 1
388 KYD-MC60G-00 0926220H ASSY_GEAR 1
389 KYD-MC603-00 016S1062 ASSY_LEVER 1
390 KYD-MC61E-00 211DA183 PLATE 1
391 KYD-MC61L-00 216D0470 PIN_HINGE 1
392 95302-03700 221FA006 NUT_HEX 1 M3
393 KYD-MC60S-00 211AE211 COVER(HIRA-1) 1
394 KYD-MC60P-00 211AE035 COVER(HIRA-2) 1
395 KYD-MC619-00 0926C20N SPRING_COMP 1
396 KYD-MC60Y-00 216S3043 LEVER(MAKITORI) 1
397 KYD-MC61T-00 216F0897 PIN_GUIDE 1
398 KYD-MC61J-00 213C0214 ROLLER(A) 1
399 KYD-MC61K-00 213C0255 ROLLER 1
3A0 KYD-MC61M-00 216D0471 PIN_HINGE 1
3A1 KYD-MC422-00 222M1321 SPRING_COMP 1
3A2 KYD-MC22D-00 216F0885 PIN_GUIDE(BANE) 1
3A3 KYD-MC410-00 4M130019 DC_MOTOR 1 M93,M94
3A4 90933-03J683 222D0377 BEARING,RADIAL 4
3A6 KYD-MC61N-00 216D0472 PIN_HINGE 1
3A7 90990-01J135 221AA089 BOLT_HEX-SCT 3 M2.5L6 SW+FWS
3A8 90990-01J139 221AA092
BOLT,HEX.S/H WW 2 M3L8 SW+FW
3B2 90990-01J138 221AA099 BOLT,HEX.S/H WW 2 M3L6 SW+FW
3B3 KYD-MC60B-00 023E0033 ASSY_GEAR 1
3B4 KYD-MC423-00 223E0415 GEAR 1
3B6 KYD-MC61C-00 211D9914 PLATE 1
3B7 KYD-MC61D-00 211D9915 PLATE 1
3B8 90166-02JA08 221DA007 SCREW,PAN HEAD 5 PAN M2.5L8
3B9 KYD-MC61G-00 211F8853 BRACKET 1
3C0 KYD-MC61X-00 221E0312 BOLT 1
3C1 90167-02J204 221DA101 MACHINE SCREW 2 FLT M2L4
3C2 KYD-MC41R-00 216A1533 COLLAR(HASUBA) 1
3C3 KYD-MC618-00 0926C20B COVER 1
3C4 KYD-MC61S-00 216D0614 PIN_HINGE 1
3C5 KYD-MCN3A-00 0926B400 SEAL 1
3D4 KYD-MC13Y-00 23G10088 SENSOR_PHOTO 1 B03
3D9 KYD-MC13N-00 216E1489 PIN_LOCATE 2
3E1 90990-02J037 221C0100 SET SCREW(SET SCREW) 4 SET M2L3
3B0 90440-01J020 221KA002 RING E 020W 3
3B1 90440-01J025 221KB002 RING E 025W 2
3B5 KYD-MC61R-00 216D0501 PIN_HINGE 1
1710-006
– 118 –
44,56mm
Q
5 Suppressor Section
1710-006
See Fig.Q-1
Key No.6
See Fig.Q-1
Key No.1
For 56mm
1
451
443
456
459
4B3
4B4
4B2
4B3
4B2
4A7
4A6
4A8
4B6
4B7
4B8
