– 119 –
Tape Feeder GT-44562
No.
Part No.
Part Name Qty. Detail
Yamaha Hitachi
443 KYD-MC60N-00 211AD950 COVER(RC) 1
451 98702-03006 221DA106 MACHINE_SCREW 2 FLT M3L6
456 KYD-MC61A-00 211A9426 COVER 1
459 98502-03006 221DA010 SCREW,PAN HEAD 2 PAN M3L6
4A6 KYD-MC609-00 216S3290 LEVER(SUP) 1
4A7 KYD-MC61P-00 216D0500 PIN_HINGE(SUP) 1
4A8 KYD-MC22K-00 222P0201 SPRING_TORSION 1
4A9 KYD-MC60A-00 016J0027 ASSY_HOOK 1
4B0 KYD-MC41W-00 216D0467 PIN_HINGE(FRONT) 1
4B1 KYD-MC620-00 222M1309 SPRING_COMP 1
4B2 KYD-MC60V-00 211DD967 PLATE(SUP) 1
4B3 KYD-MC22G-00 221D0196 MACHINE_SCREW 3 PAN M2L1.5
4B4 90990-02J023 221CA027 SCREW,SET 1 SET M4L4
4B6 KYD-MC604-00 0804000H NAME_PLATE 1
4B7 KYD-MC22H-00 221H0230 WASHER 1
4B8 90167-02JA06 221DA103 MACHINE SCREW 1 FLT M2.5L6
