– 56 – 8mm M 5 Suppressor Section 1710-006 See Fig.M-1 Key No.B1 4C2 4D2 4D6 4D5 4D8 4D4 4D7 4D7 4D1 4D3 4A5 4B3 4B2 4C6 4C5 4C8 4C4 4C7 4C7 4C3 4C1 4A5 473 4B3 454 445 446 4B2 473 4B2-03 KYD-MC17P-00 KYD-MC17R-00 KYD-MC…
– 55 –
Tape Feeder GD-28081,28083
No.
Part No.
Part Name
Qty.
Detail
Yamaha Hitachi
GD-28081 GD-28083
334 90166-02J208 221DA003 SCREW,PAN HEAD 4 4 PAN M2L8
382 KYD-MC13T-00 222M1329 SPRING_COMP 2 2
385 KYD-MCN3L-00 213C0207 ROLLER(A) 2 2
386 KYD-MCN3X-00 216F0998 PIN_GUIDE 1 1
387 KYD-MC129-00 0926B201 SPRING_COMP 2 2
389 KYD-MCN2G-00 4M130018 MOTOR_DC 2 2 M91,M92
391 KYD-MCN3T-00 216E1732 PIN_LOCATE 2 2
392 90990-01J135 221AA089 BOLT_HEX-SCT 4 4 M2.5L6 SW+FWS
393 90990-01J142 221AA107 BOLT_HEX-SCT 2 2 M3L14 SW+FW
394 90440-01J025 221KB002 RING_E_025W 2 2
395 90990-02J037 221C0100 SET SCREW(SET SCREW) 1 1 SET M2L3
396 KYD-MCN3Y-00 216K0159 SET_COLLAR 2 2
3A2 KYM-M8610-00 223E0516 GEAR 1 1
3A3 KYD-MCN39-00 0926B20W GEAR 1 1
3A4 KYD-MC11X-00 211AC677 COVER(MAKI-2) 1 1
3A5 KYD-MCN3R-00 216E1539 PIN_LOCATE 2 2
3A6 90166-12J204 221DA060 MACHINE SCREW 1 1 PAN M2L6 SW+FWS
3A9 KYD-MCN28-00 211AB091 COVER 1 1
3B2 90440-01J020 221KA002 ROHS_RING 1 1 E RING 2
3C2 KYM-M8610-00 223E0516 GEAR
1 1
3C3 KYD-MCN39-00 0926B20W GEAR 1 1
3C4 KYD-MC11X-00 211AC677 COVER(MAKI-2) 1 1
3C5 KYD-MCN3R-00 216E1539 PIN_LOCATE 2 2
3C6 90166-12J204 221DA060 MACHINE SCREW 1 1 PAN M2L6 SW+FWS
3C9 KYM-M860X-00 211AB090 COVER 1 1
3D2 90440-01J020 221KA002 ROHS_RING 1 1 E RING 2
3E1 KYD-MCN0S-00 016S1019 ASSY_LEVER 1 1
3E2 KYK-M864C-00 223E0499 GEAR 1 1
3E3 KYD-MC13P-00 216E1731 PIN_LOCATE 1 1
3E4 KYD-MC13F-00 211G5776 BLOCK(L) 1 1
3E5 90167-02JA06 221DA103 MACHINE SCREW 1 1 FLT M2.5L6
3E6 90166-12JA02 221DA008 MACHINE_SCREW 2 2 PAN M2.5L6 SW+FWS
3F1 KYD-MCN67-00 016S1018 ASSY LEVER 1 1
3F2 KYK-M864C-00 223E0499 GEAR 1 1
3F3 KYD-MC13P-00 216E1731 PIN_LOCATE 1 1
3F4 KYD-MC13G-00 211G5777 BLOCK(R) 1 1
3F5 90167-02JA06 221DA103 MACHINE SCREW 1 1 FLT M2.5L6
3F6 90166-12JA02 221DA008 MACHINE_SCREW 2 2 PAN M2.5L6 SW+FWS
3G1 KYD-MC13Y-00 23G10088 SENSOR_PHOTO 1 1
3G2 KYD-MCN3B-00 0926B401 SEAL 2 2
3G3 KYD-MCN3A-00 0926B400 SEAL 1 1
3H1 KYM-M8618-00 0926B20L ASSY LEVER 1 1
3H2 KYD-MC13S-00 221F0137 NUT_HEX 1 1 M3
3H3 KYD-MC13R-00 216F1000 PIN_GUIDE(BANE) 1 1
3H6 KYM-M8619-00 0926B20M ASSY_LEVER(R) 1 1
3H7 KYD-MC13S-00 221F0137 NUT_HEX 1 1 M3
3H8 KYD-MC13R-00 216F1000 PIN_GUIDE(BANE) 1 1
1710-006
– 57 –
Tape Feeder GD-28081,28083
No.
Part No.
Part Name
Qty.
Detail
Yamaha Hitachi
GD-28081 GD-28083
445 KYD-MCN3J-00 211DD071 PLATE 1 1
446 90990-06J004 221A0231 BOLT,HEX-SCT 2 2
454 KYD-MCN3G-00 211AD802 COVER(MOTOR) 1 1
473 90990-01J120 221A0298 BOLT,HEX-SCT 4 4 M2L5
4A5
KYD-MCN42-00 222M1492 SPRING_COMP 2
KYD-MC12A-00 0926B31X SPRING_COMP 2
4B2
KYM-M861H-00 022Q0004 ASSY,SPRING,FLAT 2
KYH-M8640-00 08771301 ASSY SPRING 2
4B2-03 KYD-MC107-00 08040005 PLATE_INDEX 2
4B3 90990-08J035 221DB001 MACHINE SCREW 2 2 PAN M2L4
4C1 KYM-M860R-00 212B2303 CHUTE(R) 1 1
4C2 KYM-M8634-00 016S1051 ASSY LEVER 1
4C2 KYH-M8622-00 0926B32E ASSY LEVER 1
4C3 KYD-MCN1U-00 0926B300 BLOCK 1 1
4C4 KYD-MCN3U-00 216F0880 PIN_GUIDE 1 1
4C5 KYD-MCN3V-00 216F0881 PIN_GUIDE 1 1
4C6 KYD-MCN43-00 222P0200 SPRING_TORSION 1 1
4C7 90990-02J037 221C0100 SET SCREW(SET SCREW) 2 2 SET M2L3
4D1 KYM-M864S-00 212B2304 CHUTE(L) 1 1
4D2 KYM-M8635-00 016S1052 ASSY LEVER 1
4D2 KYH-M8623-00 0926B32D ASSY LEVER 1
4D3 KYD-MCN1U-00 0926B300 BLOCK 1 1
4D4
KYD-MCN3U-00 216F0880 PIN_GUIDE 1 1
4D5 KYD-MCN3V-00 216F0881 PIN_GUIDE 1 1
4D6 KYD-MCN43-00 222P0200 SPRING_TORSION 1 1
4D7 90990-02J037 221C0100 SET SCREW(SET SCREW) 2 2 SET M2L3
1710-006
GD-28081 のサプレッサ (4C2,4D2) を直前剥離タイプにする場合は、
GD-28083 用の部品 (4C2,4D2,4A5,C6) へセットで交換してください
When suppressor (4C2, 4D2) of GD-28081 is to be of the immediately preceding peeling type,
Please replace it with a set for the GD-28083 (4C2, 4D2, 4A5, C6)
