Momentum ® II 100 Options that add Capability and Value to your Process NEW Paste Heigh t Monitor The Paste Height Monitor is designed to prevent defects caused by inadequate volumes of paste on the stencil. It combines …

Meeting the

Challenges

The Momentum II 100

is designed to meet the

ever-growing challenges

of today’s electronics

manufacturing world:

high performance, user-

friendly, flexible, space and

operational efficient.

Momentum® II

100

Momentum’s

Patented Technology

• Paste Management System

• RapidClean™

• StencilVision™

• Closed-loop

SPI Print Optimizer

• Benchmark™ 5.0

EXCEPTIONAL VALUE

The Momentum® II 100 delivers performance that one would expect to find only

in higher-priced printing machines. This hard-working printer utilizes the robust,

reliable Momentum® series platform that has been proven to be at the top of its

class in facilities around the world, yet its value pricing makes the Momentum® II

100 an incredible bargain.

Cost-efficient and featuring a modest footprint, it grows with the user; innovative

patented features can be added on or retrofitted as needed as the user’s

throughput demands grow.

The Momentum® II 100 can accommodate a wide range of PCB sizes from 609.6

mm x 508 mm (24” x 20”) down to is 50.8 mm x 50.8 mm (2” x 2”). Momentum’s

alignment repeatability is ±11 microns @ 6 sigma, Cpk ≥2 with a wet print accuracy

of ±17 microns @ 6 Sigma, Cpk ≥2.0. Tighter performance tolerances mean higher

repeatability with fewer defects. Plus, a cycle time of 11 seconds ensures moderate

to high throughput for its size. Programmable and closed-loop squeegee systems

ensure accurate and repeatable squeegee force with every print stroke; the system

auto-compensates for squeegee deflection, and no force adjustment is needed for

squeegee variations. For basic, repeatable printing quality with high yields and true

affordability, the Momentum® II 100 has no equal.

Momentum® II 100 New Features

¡ Newly designed cover set with

larger window and wider

access inside the printer.

¡ Quick release squeegee for

faster changeover.

¡ Adjustable stencil shelf for

exibility handling board

varieties.

¡ New jar paste dispenser

for increased productivity.

¡ Solder paste roll height

and paste temperature

monitoring for yield

improvement and

traceability.

¡ Upgraded Benchmark

GUI with customizable

production page and

Quickstart program.

¡ Windows 10 operating system.

Momentum® II 100

Options that add Capability and Value to your Process

NEW Paste Height Monitor

The Paste Height

Monitor is designed to

prevent defects caused

by inadequate volumes

of paste on the stencil.

It combines advanced

software and sensor technology to accurately monitor the

paste bead for volume consistency. Upper and lower limit

roll-height monitoring eliminates insufficient or excess paste

volumes. It is a non-contact solution that can automatically

add more paste to the stencil as it is needed.

NEW Paste Temperature Monitor

Temperature monitoring

ensures proper paste

viscosity to avoid

bridging and voiding.

MPM patent-pending

paste temperature

monitor allows paste

to be measured in the

cartridge or on the

stencil.

Updated Benchmark™ User Interface

Easy to learn and use for the average operator, MPM’s

Benchmark software is powerful yet intuitive, and facilitates

rapid setup, assists with operational tasks, and makes

changeover quick and

easy. The software

has been upgraded

to Windows 10 and

new production tools

and new Quickstart

programming to make it

even easier to use.

OpenApps™

MPM’s OpenApps is an open architecture source code which

provides the capability of developing custom interfaces in

support of Industry 4.0 initiatives and communication with

Manufacturing Execution Systems (MES). ITW EAE is the rst

SMT company to oer open software architecture.

NEW Automatic Paste Dispensing System

Dispense for standard

cartridges or choose the

new patent-pending

jar dispenser. Paste

is released in precise,

measured amounts

across the stencil in a

clean, uniform bead. Deposition volumes, frequency and

placement are user programmable.

NEW Quick Release Squeegee

New quick release

squeegee blades makes

changing blades quick

and easy with no tools

required. It takes less

than 30 seconds to

change the blade.

NEW Adjustable Stencil Shelf

Provides the exibility to handle all stencil sizes with

a simple adjustment of the shelf. The robust design

provides better stability on all stencil sizes.

MPM Vision System & Inspection

MPM’s patented printer-

based Vision and Inspection

system is a cost-eective

way to verify print and

paste deposit results. It is

exible enough to handle

the complete range of today’s most challenging components.

This system measures the amount of paste covering the

target pad and compares it with the required coverage. 2D

inspection is integrated directly into the stencil printer to

provide an immediate source of data.

RapidClean

RapidClean is a high-speed stencil solvent cleaning innova-

tion that slashes cycle time and improves stencil cleaning

performance. RapidClean can save up to $10K USD per

annum in paper savings per printer.

Momentum II 100 SPECIFICATIONS

BOARD HANDLING

Maximum Board Size (X x Y) 609.6 mm x 508 mm (24” x 20”)

A dedicated workholder is required for boards with an X size greater than 20”

Minimum Board Size (X x Y) 50.8 mm x 50.8 mm (2” x 2”)

Board Thickness 0.2 mm to 5.0 mm (0.008” to 0.20”)

Maximum Board Weight 4.5 kg (10 lbs)

Board Edge Clearance 3.0 mm (0.118")

Underside Clearance 12.7 mm (0.5") standard. Configurable for

25.4 mm (1.0”)

Board Hold-Down Fixed top clamps, centernest vacuum

Board Support Methods Magnetic pins

Optional: Vacuum side dams, vacuum pins,

support blocks, dedicated fixtures, patented

auto tooling, Quik-Tool

PRINT PARAMETERS

Maximum Print Area (X x Y) 609.6 mm x 508 mm (24” x 20")

Print Gap (Snap-off) 0 mm to 6.35 mm (0" to 0.25")

Print Speed 0.635 mm/s - 304.8 mm/s

(0.025 in/s - 12 in/s)

Print Force 0 to 22.7 kg (0 lb to 50 lbs)

Stencil Frame Size 737 mm x 737 mm (29" x 29")

Adapters available for smaller sizes

VISION

Vision Field-of-View (FOV) 10.6 mm x 8.0 mm (0.417” x 0.315”)

Fiducial Types Standard shape fiducials (see SMEMA

standards), pad/aperture

Camera System Single digital camera

- MPM patented look up/down vision

PERFORMANCE

Total System Alignment ±11 microns (±0.0004”) at 6 sigma,

Accuracy and Repeatability Cpk ≥2.0*

Qualification is performed using production environment process variables; print

speed, table lift and camera movement are included in the capability figure.

Wet Print Deposit ±17 microns (±0.0007”) at 6 sigma,

Accuracy and Repeatability Cpk ≥2.0*

Based upon actual wet printing with positional accuracy and repeatability verified by

a 3rd party measurement system.

Cycle Time 11 seconds standard

FACILITIES

Power Requirements 200 to 240 VAC (±10%) single phase @

50/60Hz, 15A

Air Supply Requirements 100 psi at 4 cfm (standard run mode) to 18

cfm (vacuum wipe) (7 bar @ 5 L/s to 12 L/s),

12.7 mm (0.5”) OD x 9.5 mm (3/8”) ID line

Height (excluding light tower) 1494.10 mm (58.82”) at 940 mm (37.0”)

transport height

Machine Depth 1423.5 mm (56.04")

Machine Width 1196.0 mm (47.09”)

Minimum Front Clearance 508 mm (20.0”)

Minimum Rear Clearance 508 mm (20.0”)

Machine Weight 797 kg (1757 lbs)

Crated Weight 1090.5 kg (2404 lbs)

* The higher the Cpk, the lower the variability with respect to the process specification limits. In a

process qualified as a 6 sigma process (i.e., one that allows plus or minus 6 standard deviations within

the specification limits), the Cpk is greater than or equal to 2.0.

Specification is subject to change without notice. Please consult factory for specifics.

ITW EAE maintains an ongoing program of product improvement that may affect design and/or price.

We reserve the right to make these changes without prior notice or liability.

www.itweae.com

ITW EAE is a division of Illinois Tool Works, Inc. It is a consolidation of all of its Electronic Assembly

Equipment and Thermal Processing Technology. The group includes world-class products from MPM,

Camalot, Electrovert (Speedline), Vitronics Soltec and Despatch.

MPM Printers – Built on a Solid Foundation.

Strength and stability are prerequisites for accuracy and precision when system parts are in motion and moving

about at high speed. The Momentum® II 100’s major assemblies are driven by precision ball screws, not belts,

which eliminate the need for calibrations. The worknest and camera gantry are designed for optimum motion

stability, shorter settling time, and faster board and stencil alignment. Momentum® II 100’s rigid frame is welded

for low vibrations. This allows for higher repeatability and great reliability over time. Alignment is achieved with

minimum motion; thus the PCB travels to the stencil more quickly.
