suneas t.co m.cn 3 - 3 . 助焊 剂回收 系统 F l ux e r R ec ov er y s y s t e m 图片 p i c t u r e 12
suneast.com.cn
特点：Feature
①分级助焊剂过滤,确保助焊剂高效处理
Multi-level fluxer filtering to ensure high-activity processing
②维护保养方便快捷，无需工具
Easy and efficient to maintenance without tools
③维护保养不需要停机（在线维护保养）
No need to turn off the machine to maintain ( on-line maintenance)
11
3-2. 助焊剂回收系统
Fluxer Recovery system
suneast.com.cn
3-3. 助焊剂回收系统
Fluxer Recovery system
图片 picture
12
suneast.com.cn
4-1. 传输系统（高可靠性，防传输导轨变形设计）
Conveyor system(High reliability, rail deformation prevention
design)
13
特点：Feature
①导轨采用特殊铝合金材质，表面超硬膜氧化处理（防变形、防磨损）The rails is
adopting special aluminum alloy and doing superhard and oxidation treatment in
surface( anti-distortion , anti-wear )
②导轨采用两段式结构设计，增强导轨抗弯强度，防变形The rails is adopting two
section structure design to enhance the bending resistance of the rail, anti
distortion.)
③ 特殊调宽及传输结构设计，保证PCB传输稳定可靠Special width adjustment and
conveyor structure design to ensure PCB conveying stable and reliable.
④手动+电动调宽结构设计Manual + electrical width adjustment structure design
⑤ 配置紧急手动传输结构，以防断电烧坏炉膛内的PCB Equipped with emergency
manual conveyor structure to prevent PCB burned when the power is off.
