Page HANWHA 7 SME 4 mm SME Tape Feeder - Total NO. LEVEL P ART NO. P ART NAME Q'TY TYPE OLD NO. Reference 28 J600530053 8 BUTTON HEAD SOC KET SCRE W 2 29 FC07-001049A DUMP BOX COVER2 W4P1 1 30 J70653701A SLICING OUT…
Page
HANWHA
6
SME
4mm SME Tape Feeder - Total
NO. LEVEL PART NO. PART NAME Q'TY TYPE OLD NO. Reference
1 FC39-001302A MAIN BODY SME W4P1 1
2 J70653552A D-TENSIONER_HINGE J70653552A 1
3 J72651198A D-TENSIONER ROLLER 2
4 MC19-000643A DRAIN HANDLE SHAFT 1
5 J70653926A PAN CAP SCREW M25L35 5
6 J64091017A MAGNET HXNS1-5 1
7 J70653940A FLAT TAPPING SCREW 3X7-2 12
8 J7065980A HANGER SHAFT GUIDE 1
9 J72651326A PCB COVER M 08 1
10 J6006300650 FLAT HEAD CAP SCREW 8
11 FC15-001975A D-BOX COVER SME-W4P1 1
12 J6004300450 BUTTON HEAD CAP SCREW 3
13 AM03-001815C ASSY,BOARD-MF MAIN BOARD 1
14 J70653748A D-DOOR PIN M 08 1
15 FC24-000043A D-BOX DOOR SME W4P1 1
16 J71651939A HEAT SINK M 08 1
17 J70653696A D-BOX LEVER M 08 1
18 J70653697A D-MOTOR COVER M 08 1
19 FC15-002324A RIGHT COVER M 08 1
20 FC07-000971A DRAIN COVER W4P1 1
21 FC07-000970A DRAIN GEAR FORK-W4P1 1
22 J70653933A D-STAGE GEAR SHAFT 1
23 GD03-000049A D-STAGE GEAR1 1
24 MC11-001010A DRAIN GEAR-1 W4P1 1
25 MC19-000660A DRAIN COVER SHAFT 1
26 J6005300838 BUTTON HEAD SOCKET SCREW 5
27 FC15-002039A DUMP BOX COVER M 08 W4P1 1
Page
HANWHA
7
SME
4mm SME Tape Feeder - Total
NO. LEVEL PART NO. PART NAME Q'TY TYPE OLD NO. Reference
28 J6005300538 BUTTON HEAD SOCKET SCREW 2
29 FC07-001049A DUMP BOX COVER2 W4P1 1
30 J70653701A SLICING OUTER COVER M 08 1
31 J90652110A SPLICING M 08 ASSY 1
32 J31021017A SM-V DRAIN MOTOR 1
33 J90650183C HANGER ASSY 1
34 J90611845A DRAIN SENSOR HARNESS ASSY M 08 1
35 AM03-008090A SECOND GEAR M 08 ASSY 1
36 J91741352A INDEX SENSOR ASSY 1
37 J90652099A D-TENSIONER M 08 ASSY 1
38 J70661458A TAPE GUDIE SHAFT1 M 08 1
39 AM03-007525A INDEX MOTOR SME08 ASSY 1
40 J70653745A SECOND PINION 08 1
41 MC19-000514A GEAR SHAFT SCREW 1
42 J70661458A TAPE GUDIE SHAFT1 M 08 1
43 J1301149 E RING (4) 2
44 J7066026A T-COVER 1
45 FC07-000972B BLOCK-PICKUP BLOCK 4W1P 1 FC07-000972A
46 MC19-000661A SHAFT-PICKUP BLOCK SHAFT W4P1 2
47 J90652097A LOCKER M 08 ASSY 1
48 J70661457A LOCKER HINGE M 08 2
49 J70652174A X ECCENTRIC PIN 1
50 J7066033B LOCKER SPG PIN2 1
51 J70650948B LOCATION FLANGE 1
52 J6010300438 SOCKET SET SCREW(M3X0.5 L4) 2
53 AM03-010170A MOTOR GEAR SHAFT1 ASSY 1
54 MC19-000492A FIRST METAL BEARING 1
Page
HANWHA
8
SME
4mm SME Tape Feeder - Total
NO. LEVEL PART NO. PART NAME Q'TY TYPE OLD NO. Reference
55 J72651377A DUMP BOX DOOR 1
56 FC18-000694 TRUSS HEAD SRCREW M3L5 2
57 J90652111A D-GEARTRAIN M 08 ASSY 1
58 J6004301250 FLAT HEAD CAP SCREW 3
59 GD03-000023A INSTALL GUIDE 1
60 J70650994B TOGGLE STOPPER 1
61 J70650995B TOGGLE SPG PIN 1
62 J7065992B BOTTOM LOC PIN 1
63 J90652106A TOGGLE M 08 ASSY 1
64 J7065981A PROBER COVER 1
65 AM03-001245A Main Probe Harness ASSY M 08 1
66 J90611844A CLAMP_SWITCH_HARNESS_ASSY_M_08 1
67 J90652105A REEL PLATE M 08 ASSY 1
68 GD03-000055A UI BLOCK M 08 1
69 J71651465A MAIN LED LIGHT 1
70 J70652749A VINYL_CUTTER 1
71 J91741353A UI ASSY M08 1
72 J70661463A CLAMP LEVER SHAFT M 08 1
73 J1301023 E RING(3) 1
74 J70653699A MOTOR COVER M 08 1
75 J70653694A CLAMP LEVER M 08 1
76 J70650967C LOCKING LIMIT 1
