Page HANWHA 23 SME 12 mm SME Tape Feeder - Total NO. LEVEL P ART NO. P ART NAME Q 'TY TYPE OLD NO. Reference
Page
HANWHA
22
SME
12mm SME Tape Feeder - Total
NO. LEVEL PART NO. PART NAME Q'TY TYPE OLD NO. Reference
28 S60060006A FHCS 4 S60060006A M4*8
29 S60010003A SHCS 2 S60010003A M4*10
30 J1301154 FLAT WASHER 1 S60420001A M3 (SUS)
31 J1301023 SNAP RING 1 S60710002A DIA3 (SUS)
32 AM03-001784A SPROCKET SENSOR BOARD ASSY 1 S91000018A
33 AM03-001785A SPROCKET SENSOR CABLE ASSY 1 S91000001A
Page
HANWHA
23
SME
12mm SME Tape Feeder - Total
NO. LEVEL PART NO. PART NAME Q'TY TYPE OLD NO. Reference
Page
HANWHA
24
SME
12mm SME Tape Feeder
