Page HANWHA 30 SME 12 mm SME Tape Feeder - Total NO. LEVEL P ART NO. P ART NAME Q 'TY TYPE OLD NO. Reference 2 J7065 0978C INST ALL GUIDE 1 3 FC18-000205A BTM LOC' PIN 1 S700000 01A 4 J7065 0948B LOCA TION FLAN…
Page
HANWHA
29
SME
12mm SME Tape Feeder - Sub (6)
1
6
8
10
12
11
4
9
3
5
2
7
13
12
12
P
Page
HANWHA
30
SME
12mm SME Tape Feeder - Total
NO. LEVEL PART NO. PART NAME Q'TY TYPE OLD NO. Reference
2 J70650978C INSTALL GUIDE 1
3 FC18-000205A BTM LOC' PIN 1 S70000001A
4 J70650948B LOCATION FLANGE 1
5 FC18-000204A FRONT GUIDE PIN 1 S70000002A
14 S66010003A BEARING 1 S66010003A
Page
HANWHA
31
SME
12mm SME Tape Feeder - Total
NO. LEVEL PART NO. PART NAME Q'TY TYPE OLD NO. Reference
D EP08-000035A MOTOR ASSY 1 S90000011A
F AM03-001462A VINYL DISCHARGE ASSY 1 S90000013A
1 FC39-000730A DISCHARGE FRAME 1 S72000010A
2 MC19-000342A VINYL FIX ROLLER PULLEY 1 S72000011A
