Page HANWHA 47 SME 16 mm SME Tape Feeder - Sub NO. LEVEL P ART NO. P ART NAME Q'TY TYPE OLD NO. R eference D EP08-000035A MOT OR ASSY 1 S900000 1 1A F AM03-001462A VINYL DISCHARGE AS SY 1 S90000013A 1 FC39-00 0730A …
Page
HANWHA
46
SME
16mm SME Tape Feeder - Sub
NO. LEVEL PART NO. PART NAME Q'TY TYPE OLD NO. Reference
2 J70650978C INSTALL GUIDE 1
3 FC18-000205A BTM LOC' PIN 1 S70000001A
4 J70650948B LOCATION FLANGE 1
5 FC18-000204A FRONT GUIDE PIN 1 S70000002A
17 J66011014A BALL_BEARING_F605ZZ-STF100N F605ZZ 1 S66010003A
Page
HANWHA
47
SME
16mm SME Tape Feeder - Sub
NO. LEVEL PART NO. PART NAME Q'TY TYPE OLD NO. Reference
D EP08-000035A MOTOR ASSY 1 S90000011A
F AM03-001462A VINYL DISCHARGE ASSY 1 S90000013A
1 FC39-000730A DISCHARGE FRAME 1 S72000010A
2 MC19-000342A VINYL FIX ROLLER PULLEY 1 S72000011A PULLEY FLANGE included
Page
HANWHA
48
SME
16mm SME Tape Feeder - Sub
NO. LEVEL PART NO. PART NAME Q'TY TYPE OLD NO. Reference
9 AM03-005003A VINYL SEPARATOR 1 1 S72000013A
10 J66011086A BALL_BEARING MF106ZZS 2 S66010005A
G FC35-000077A VINYL EXIT ROLLER ASSY 1 S90000018A
H AM03-005013A VINYL EXIT MOVING ASSY 1 S90000023A
