SME_FEEDER_TRM(Ver3.7_CS18.01).pdf - 第62页
Page HANWHA 50 SME 16 mm SME Tape Feeder - Sub NO. LEVEL P ART NO . P AR T NAME Q 'TY T YPE OLD NO. Reference 8 AM03-001455 A LIMIT SWITCH CABLE ASSY 1 S910 00007 10 FC18-000479A FHCS 7 S60060004A 1 1 J6006201050 FH…
Page
HANWHA
49
SME
16mm SME Tape Feeder - Sub
NO. LEVEL PART NO. PART NAME Q'TY TYPE OLD NO. Reference
J J90651523A LOCKER ASSY 1
K AM03-001477A SME TAPE GUIDE 16MM ASSY 1 S90000030A
1 FC38-000071A VINYL COVER LEVER SPRING 1 S70000059A
2 FC18-000480A FHCS 2 S60060001A
L AM03-005021A VINYL ADT. ASSY 1 S90000036A
M AM03-005022A TAPE GUIDE SHUTTER ASSY 1 S90000038A
N AUX. ASSY 1
1 FC30-000800A AUX. PLATE 1 S71000021A
2 FC28-000327A LINK COVER 1 S72000033A
3 FC29-001089A GRIP NUT 1 S70000080A
4 J7265131A DAMPER 1
5 J7065802A DAMPER WASHER 1
6 J9065092A STOPPER ASSY 1
7-1 EP06-000087A MAIN BOARD(IT) 1 S91000002A
Page
HANWHA
50
SME
16mm SME Tape Feeder - Sub
NO. LEVEL PART NO. PART NAME Q'TY TYPE OLD NO. Reference
8 AM03-001455A LIMIT SWITCH CABLE ASSY 1 S91000007
10 FC18-000479A FHCS 7 S60060004A
11 J6006201050 FHCS 2 S60060002A
12 FC18-000474A BHCS 2 S60050001A
13 FC18-000476A BHCS 2 S60050003A
14 J6025200050 NUT 2 S60250001A
16 J1301149 SNAP RING 2 S60710003A
O S90000056A FEEDER CLAMP ASSY 1
1 J90651524A CLAMP LEVER ASSY 1
2 S90000057A T_LINK ASSY 1
2-1 AM03-001448A T_LINK2 ASSY 1
2-2 J70650996B T_LINK1 1
2-3 J70660007C T_LINK1 SHAFT2 1
2-4 J70652737A T_LINK3 1
2-5 J70660002C T_LINK2 SHAFT 2 1
2-6 J70652736A T_LINK4 1
2-7 J70660029B T_LINK3 SHAFT1 1
2-8 FC28-000118A T_LINK5 1
2-9 J70652727A T_LINK4 PIN 1
2-10 S60710003A SNAP RING 1
2-11 S60710002A SNAP RING 3
3 MC19-000344A T_LINK5 SHAFT 1 1
4 S60710004A SNAP RING 1
Page
HANWHA
51
SME
16mm SME Tape Feeder - Sub
NO. LEVEL PART NO. PART NAME Q'TY TYPE OLD NO. Reference
P HANDLE ASSY 1
5 AM03-001786A SWITCH BOARD ASSY 1 S91000003A
6 AM03-001787A SWITCH BOARD CABLE ASSY 1 S91000004A
9 AM03-001791A SPLICE_BOARD_ASSY 1 S91000010A
10 AM03-001789A SPLICING SENSOR CABLE ASSY 1 S91000006A
11 FC29-001091A SPLICING GUIDE_16 1 S72000039A
Q AM03-001460A 16MM REEL ARM PLATE ASSY 1
R AM03-001449A PROBE CABLE ASSY (IT) 1 J91672413A
S S91000008A IT BOARD IF CABLE ASSY 1
T MC11-000383A GEAR-DROP GEAR ASSY 1 S90000010C03 S90000010A
