SME_FEEDER_TRM(Ver3.7_CS18.01).pdf - 第75页
Page HANWHA 63 SME 24 mm SME Tape Feeder - Sub NO. LEVEL P ART NO. P ART NAME Q'TY TYPE OLD NO. Reference D EP08-000035A MOTOR ASSY 1 S9000001 1A F AM03-001500AA VINYL DISCHARGE ASSY 1 S90000014 1 FC39-000730A DISCH…
Page
HANWHA
62
SME
24mm SME Tape Feeder - Sub
NO. LEVEL PART NO. PART NAME Q'TY TYPE OLD NO. Reference
2 J70650978C INSTALL GUIDE 1
3 FC18-000205A BTM LOC' PIN 1
4 J70650948B LOCATION FLANGE 1
5 FC18-000204A FRONT GUIDE PIN 1
14 J66011014A BALL_BEARING_F605ZZ-STF100N F605ZZ 1 S66010003A
Page
HANWHA
63
SME
24mm SME Tape Feeder - Sub
NO. LEVEL PART NO. PART NAME Q'TY TYPE OLD NO. Reference
D EP08-000035A MOTOR ASSY 1 S90000011A
F AM03-001500AA VINYL DISCHARGE ASSY 1 S90000014
1 FC39-000730A DISCHARGE FRAME 1 S72000010A
2 MC19-000342A VINYL FIX ROLLER PULLEY 1 S72000011A PULLEY FLANGE included
Page
HANWHA
64
SME
24mm SME Tape Feeder - Sub
NO. LEVEL PART NO. PART NAME Q'TY TYPE OLD NO. Reference
9 AM03-005005A VINYL SEPARATOR 1 1 S72000014A
10 J66011086A BALL_BEARING MF106ZZS 2 S66010005A
G FC35-000078A VINYL EXIT ROLLER ASSY 1 S90000019A
H AM03-005014A VINYL EXIT MOVING ASSY 1 S90000024A
