7 Repairs to SmartFeeder 8 mm X
7.15 Control board
Service Manual SIPLACE SmartFeeder 4 - 104 mm X 11/2017 131
Connect the 3 flat ribbon cables(4-6) to the control
board. Proceed as follows for this:
► Push the flat ribbon cable as far as the stop into
the connection shown in the diagram.
Make sure that the contacts are on the underside
of the cable and that the blue side of the cable
can be seen on the top.
► Lock the connection (see the diagram, top right).
► Insert the EDIF connector into the marked con-
nection on the control board.
► Align the position of the control board again, us-
ing the 3 holes in the control board and the 3
holes in the side cover.
► Carefully place the feeder module with the left
side down on a stable, level and clean surface,
while holding the control board in its position.
► Fasten the control board with the 3 Phillips
screws shown in the diagram(1) to the right side
cover.
► Make sure that the EDIF connector is correctly in-
serted onto the control board.
► Carefully fasten the EDIF connector with the
TORX screw shown in the diagram(2).
Use a size T8 TORX screwdriver with 0.2 Nm. for
this.
► Carefully place the feeder module with the right
side down on a stable, level and clean surface.
► Fasten the left side cover (see section 7.3.2 "Fit-
ting the left side cover" [}83]).
NOTICE
Reference run
After replacing the control board, it is essential that you perform a reference run of the
feeder module! For a detailed description, refer to section7.15.3 "Performing a reference
run" [}132].
7 Repairs to SmartFeeder 8 mm X
7.15 Control board
132 Service Manual SIPLACE SmartFeeder 4 - 104 mm X 11/2017
7.15.3 Performing a reference run
Fig.41: Control panel
1. LED 8 – 8mm pitch
(active only on SmartFeeder 8mmX)
6. FORWARDS button
2. LED 4 – 4mm pitch 7. BACKWARDS button
3. LED 2 – 2mm pitch 8. FOIL button
4. LED 1 – 1mm pitch 9. SET button
5. LED M – menu
Shines when an operator menu is active
► Place the feeder module on a single slot EDIF or on a changeover table for X feeders which is
connected to a placement machine.
► Press and hold the gray SET button(9) until the reference run is enabled.
► Press the yellow foil button three times briefly(8).
After the first press of the FOIL button, the LEDM will switch on.
After the second press, LED1 will also be switched on.
After the third press, LED2 will also be switched on.
The menu for enabling the reference run has now been selected.
► In addition to the SET button, also press the FORWARDS button(7).
LED8(1) should now flash rapidly. If LED8 and LED4(2) flash, this indicates that there is a
feeder module error present (e.g. foil is tensioned or tape drive has an error) and the refer-
ence run can not be performed.
► Release the FORWARDS button.
The reference run will start.
► Release the SET button.
The reference run will be automatically finished. The control panel will then switch over to the
pitch display.
8 Repairs to SmartFeeder 2x8 mm X
8.1 Front sliding guide/sliding foil
Service Manual SIPLACE SmartFeeder 4 - 104 mm X 11/2017 133
8 Repairs to SmartFeeder 2x8 mm X
Feeder module Item no. Description
SmartFeeder 2x8mmX 00141269-xx SIPLACE SmartFeeder 2x8 mm X
00141289-xx SIPLACE SmartFeeder 2x8mm X splice sensor
8.1 Front sliding guide/sliding foil
Required spare part
Fig.42: Sliding foil X-Feeder
Feeder module Item no. Designation
SmartFeeder 2x8mmX 03019604Sxx Front sliding guide
Required tools
●
Sliding foil remover
8.1.1 Removing the Sliding Foil
► Place the feeder on a stable, level and clean sur-
face.
► Insert the sliding foil remover into the sliding
guide.(1)
► Lever the sliding foil out of the engaged position.
► Lever the sliding foil until it has been turned by
approximately90°.
► Push the sliding foil towards the front and out of
the sliding guide.(2)
8.1.2 Fitting the Sliding Foil
► Press the sliding foil slightly together.
► Push the sliding foil from the front into the sliding guide, until it engages.
