DEK NeoHorizon 03iX SP
Machine Description
DEK NeoHorizon 03iX
SP platform – More
reliability and efficiency
for future-proof printing
The DEK NeoHorizon
03iX SP shines with more
than new design. It’s
modular interior is much
improved and highly
reliable. Whether in high-
mix contract
manufacturing or high-
volume applications with
high throughput
requirements – the DEK
NeoHorizon 03iX SP is
the right printing platform.
Benchmark for accuracy
The DEK NeoHorizon
03iX SP platform is based
on an exceptionally stable
frame design. With its
torsional rigidity and high
intrinsic resonance
frequency, the machine’s
frame provides the
foundation for longevity
and long-lasting accuracy.
With its advanced
controllers and bus
systems, the DEK
NeoHorizon 03iX SP
achieves a system
alignment capability of
±20µm @ 2Cmk
(6Sigma).
The frame provides lots of
space and the bus system
a wide range of interfaces
for basic components like
precision drives, digital
camera modules and high
precision guides and
slides, as well as for many
productivity-enhancing
options: the DEK
Productivity Tools.
State-of-the-art
software: DEK Instinctiv
With its touchscreen,
keyboard and trackball
operation, graphical
interfaces, multiple
languages and integrated
video-based help, the
DEK Instinctiv software
supports the easy, quick
and error-free operation of
the NeoHorizon 03iX SP
printer.
With ISCAN (Intelligent
Scalable Area Network),
the new configuration can
be scanned with just a
few clicks and additional
performance is available.
And thanks to its
interfaces, the DEK
NeoHorizon 03iX SP can
fine-tune its printing
process based on data
imported from modern
SPI systems.
The right configuration
for every job
High-speed production,
high-mix runs of small
lots, pin-in-paste, ultra-
fine apertures for super-
small components,
stepped stencils, PCBs
with unusual substrates,
many different paste
types – no matter what
the production
requirements are and
what processes are being
used: the DEK
NeoHorizon 03iX SP
platform always
accommodates the right
configuration for the
printing process.
B2B setup: Flexible on
two tracks
The DEK NeoHorizon
03iX SP Back-to-Back
setup makes for a
uniquely flexible dual-
track solution. Both units
remain separately
controllable, can be split
up again at any time and
use the full-size printing
area.
Faster cleaning, more
throughput
The DEK NeoHorizon
03iX offers two models of
automatic under stencil
cleaning: the IUSC as
standard or selectable
versions of the new DEK
Typhoon high-speed
under stencil cleaning
system featuring the new
optional plenum inserts
Hard Top – for standard
cleaning, Poly Blade for
cleaning irregular
undersides
6
DEK NeoHorizon 03iX SP
Machine Standard Configuration
Standard Configuration
Specification
Machine Alignment Capability
> 2.0 C
mk
@ +/- 12.5µm, (±6 Sigma)
System Alignment Capability
> 2.0 C
mk
@ +/- 20µm, (±6 Sigma)
Wet Print Capability
> 2.0 C
pk
@ +/- 25µm, (±6 Sigma)
Core Cycle Time
8 secs + process
Maximum Print Area
510mm* (X) x 508.5mm (Y)
Printer Construction
One piece optimised welded frame
ISCAN
TM
Machine Control
Motion control using CAN BUS network
Operating System
Windows 10 IoT Enterprise
Operator Interface
Colour TFT touch screen display, keyboard and
trackball with DEK Instinctiv
TM
software. Machine
mountable on either left or right hand side.
Camera
HawkEye® 750 digital camera, using IEEE 1394
interface. Multi channel. LED lighting. FOV 11.3mm x
8.7mm (split between two views). Inspection window
26mm
2
Camera Positioning
Rotary motors and encoders with 4 micron resolution
Squeegee Pressure Mechanism
Software controlled, motorised with closed loop
feedback
Stencil Positioning
Semi-Auto-Load incorporating squeegee drip tray
Stencil Alignment
Motorised via actuators X, Y, and Theta
Under Stencil Cleaning
Interchangeable Under Stencil (IUSC) cleaner, fully
programmable with wet/dry/vacuum wipe with external
solvent tank. Specify length (300mm, 400mm, 520mm)
Vacuum Assist for Under Stencil
Cleaning
On board vacuum unit 35 litres/sec airflow
Substrate Fixture
Foil-less clamps
Through table vacuum
Squeegee
Clamped double trailing edge squeegee (1 set
included)
Temperature/Humidity Sensor
Monitoring of the process environment
Machine Interface
Upline and downline FMI included
Connectivity
RJ-45LAN (networking) and USB2/3 interface available
ESD Compatibility
Compliant with EN/IEC 61340-5-1, EN/IEC 61340-5-2,
ANSI/ESD SP10.1, ANSI/ESD S20.20
Tri Colour Beacon
Programmable with audible alarm
Documentation
Hard copy manuals comprising: Operator, Installation,
Electrical Drawings. On board technical manuals and
tutorials supporting operator functions. DVD containing
manuals and tutorials.
* For print area up to 600mm long please contact the Product Manager
7
DEK NeoHorizon 03iX SP
Machine Standard Configuration
Transport System
Specification
Type
Single piece with 3mm flat transport belts, front rail
fixed
Width Adjustment
Programmable motorized rear rail
Transport Direction
Left to right
Right to left
Left to left
Right to right
Substrate Handling Size (minimum)
70mm (X) x 70mm (Y)
Substrate Handling Size (maximum)
510mm (X) x 508.5mm (Y)
Substrate Thickness
0.2mm to 6mm
Substrate Weight (maximum)
1kg
Substrate Warpage
Up to 7mm including substrate thickness
Substrate Fixture
Over the top clamps
Foiless clamps
Through table vacuum
Substrate Handling Features
Soft rail lift/land
Board clamp regulator
Substrate Underside Clearance
Programmable 3mm to 42mm
Process Parameter
Specification
Print Pressure
0kg to 20kg
Print Speed
2mm/sec to 300mm/sec
Print Gap
0mm to 6mm
Substrate Separation
Speed: 0.1mm/sec to 20mm/sec
Distance: 0mm to 20mm
Print Modes
Print/Print
Print/Flood
Flood/Print
Adhesive
Paste Knead
Programmable: number; period; on demand
