SP18 机械Parts List - 第26页
㪈㪄㪜 ᧄ ㇱ Mai n Bo dy 䊌䊷䉿䊧䉟䉝䉡䊃 Ki t N o . 䉨䉾䊃 ຠ⇟ Kit N am e 䉨䉾䊃ฬ⒓ N6 10 012 84 2AA 䍜䍖䍚䍌䍻㪥㫆㪅 PARTS LAYOUT Section No. M9 -0##
Ref
No.
Remarks
R
1
Q'ty
㪈㪄㪛
ᧄ
ㇱ
Main Body
䍐䍵䍛䍢
㪥㫆㪅
Part No.
ຠ䇭䇭ฬຠ⇟ ᢙ㊂
R
2
䊌䊷䉿䊥䉴䊃
Kit N
o
.
䉨䉾䊃ຠ
⇟
Kit Name
䉨䉾䊃ฬ⒓
N610012842AA
Part Name
䇭䇭䇭⠨
䍜䍖䍚䍌䍻㪥㫆㪅
PARTS LIST
Section No.
R
3
COUPLING
2
5 KXFB02W7A00
PLATE
2
6 N210025238AA
BRACKET
1
8 N210043225AB
BRACKET
1
9 N210026152AB
PLATE
1
10 N210026081AC
STOPPER
1
12 N210026172AA
HOLDER
1
13 N210027823AA
BRACKET
2
34 KXFB0335A00
PIN
2
91 N986MMS410 MMS4-10
BALL-SCREW
1
103 N510035668AA BLK1616-3.6ZZG0+1178LCp5R©(31964773K002)
LINEAR-WAY
2
105 N510035667AA
SSR20XW2UUC1E+1180L-II(A)(01846511G000)/(B)(01846508G000)
LINEAR-WAY
2
106 N510011031AA SSR20XW2UUC1+880L-2(01781136G000)
MOTOR
2
107 MSMD022PJA
S
MSMD022PJA
BEARING
2
108 KXF0A1QAA00 7201T2DF/GNP5
BEARING-NUT
2
109 KXF0E3M2A00 AN01
WASHER
2
110 N510020756AA KK20
SPACER
1
114 N510020436AA 3382330-50070
C-RING
2
115 KXF04CRAA00 STW-10
COLLAR
1
116 N510020759AA 87SCNPA16-10
BEARING
2
118 KXF0E3BVA00 6000ZZ
SPACER
2
119 N510009576AA 3382330-40020
BEARING-WASHER
2
120 KXF0E3LDA00 AW01
PIN
3
122 KXF0529AA00 SPP3-10
BOLT
4
135 N510017308AA
Hexagon socket head cap screw M3X12-10.9 A2J (Trivalent)
BOLT
6
138 N510017344AA
Hexagon socket head cap screw M4X10-10.9 A2J (Trivalent)
BOLT
8
139 N510017346AA
Hexagon socket head cap screw M4X12-10.9 A2J (Trivalent)
BOLT
18
140 N510017351AA
Hexagon socket head cap screw M4X16-10.9 A2J (Trivalent)
BOLT
8
141 N510017354AA
Hexagon socket head cap screw M4X20-10.9 A2J (Trivalent)
BOLT
75
146 N510017395AA
Hexagon socket head cap screw M5X16-10.9 A2J (Trivalent)
BOLT
4
147 N510017398AA
Hexagon socket head cap screw M5X20-10.9 A2J (Trivalent)
BOLT
8
152 N510017435AA
Hexagon socket head cap screw M6X20-10.9 A2J (Trivalent)
BOLT
4
153 N510017444AA
Hexagon socket head cap screw M6X45-10.9 A2J (Trivalent)
WASHER
4
155 N510018497AA
Round finish plain washer 4 10H A2J (Trivalent)
WASHER
4
159 N510018478AA
Small round-plain washer 3 10H A2J (Trivalent)
WASHER
8
160 N510018479AA
Small round-plain washer 4 10H A2J (Trivalent)
WASHER
4
162 N510018481AA
Small round-plain washer 6 10H A2J (Trivalent)
WASHER
4
164 N510020100AA Thick washer for M5
WASHER
4
165 N510018327AA Spring lock washer No.2 3 S A2J (Trivalent)
Sensor
1
188 N610026819AA Sensor:-B1020
STOPPER
1
195 N210051437AA
PLATE
1
196 N210054777AB
BALL-SCREW
1
211 N510035669AA BLK1616-3.6ZZ+1178LT(31882054K001)
Sensor
1
215 N610026817AA Sensor:-B1014
STOPPER
1
216 N210075681AA
M8
-0##
㪈㪄㪜
ᧄ
ㇱ
Main Body
䊌䊷䉿䊧䉟䉝䉡䊃
Ki
t
N
o
.
䉨䉾䊃
ຠ⇟
Kit Name
䉨䉾䊃ฬ⒓
N610012842AA
䍜䍖䍚䍌䍻㪥㫆㪅
PARTS LAYOUT
Section No.
M9
-0##
Ref
No.
Remarks
R
1
Q'ty
㪈㪄㪜
ᧄ
ㇱ
Main Body
䍐䍵䍛䍢
㪥㫆㪅
Part No.
ຠ䇭䇭ฬຠ⇟ ᢙ㊂
R
2
䊌䊷䉿䊥䉴䊃
Kit N
o
.
䉨䉾䊃ຠ
⇟
Kit Name
䉨䉾䊃ฬ⒓
N610012842AA
Part Name
䇭䇭䇭⠨
䍜䍖䍚䍌䍻㪥㫆㪅
PARTS LIST
Section No.
R
3
BRACKET
1
24 N210041741AD
AIR PARTS UNIT
1
41 N610027756AA
PLATE
1
42 N210039321AB
JOINT
2
43 KXF09ZBAA00 KQ2P-06
MANIFOLD
1
45 KXF029YAA00 KM11-08-12-6
JOINT
1
46 KXF0E16CA00 KQ2P-12
JOINT
1
47 KXF0E39DA00 KQ2R04-08
VALVE
1
48 N510016403AA VP544-5DZ-03A-X318
JOINT
2
49 KXF09UYAA00 KQ2L04-01S
JOINT
3
50 KXF0A0EAA00 KQ2R06-08
SILENCER
1
51 KXF00W9AA00 AN103-01
BOLT
2
53 N510017344AA
Hexagon socket head cap screw M4X10-10.9 A2J (Trivalent)
BOLT
4
54 N510017359AA
Hexagon socket head cap screw M4X25-10.9 A2J (Trivalent)
BOLT
2
55 N510017361AA
Hexagon socket head cap screw M4X30-10.9 A2J (Trivalent)
BOLT
2
56 N510017401AA
Hexagon socket head cap screw M5X30-10.9 A2J (Trivalent)
WASHER
4
57 N510018497AA
Round finish plain washer 4 10H A2J (Trivalent)
WASHER
4
58 N510018479AA
Small round-plain washer 4 10H A2J (Trivalent)
NIPPLE
1
83 N510021600AA VRN-0302
JOINT
1
84 N510019579AA (L)3/8
HOSE
1
85 N510002541AA OUA8X12-5M-03B
BOTTLE
1
86 KXF07M8AA00 5-010-03
FILTER
1
87 N510016407AA AFM20-02BC-R-X2106
BAND
1
97 N510011271AA G-12
BOLT
4
137 N510017381AA
Hexagon socket head cap screw M4X8-10.9 A2J (Trivalent)
BOLT
6
138 N510017344AA
Hexagon socket head cap screw M4X10-10.9 A2J (Trivalent)
BOLT
6
139 N510017346AA
Hexagon socket head cap screw M4X12-10.9 A2J (Trivalent)
BOLT
4
143 N510017419AA
Hexagon socket head cap screw M5X8-10.9 A2J (Trivalent)
BOLT
3
144 N510017386AA
Hexagon socket head cap screw M5X10-10.9 A2J (Trivalent)
BOLT
2
145 N510017390AA
Hexagon socket head cap screw M5X12-10.9 A2J (Trivalent)
WASHER
6
155 N510018497AA
Round finish plain washer 4 10H A2J (Trivalent)
WASHER
7
156 N510018499AA
Round finish plain washer 5 10H A2J (Trivalent)
WASHER
4
160 N510018479AA
Small round-plain washer 4 10H A2J (Trivalent)
WASHER
6
163 N510020099AA Thick washer for M4
WASHER
2
164 N510020100AA Thick washer for M5
WASHER
6
166 N510018330AA Spring lock washer No.2 4 S A2J (Trivalent)
BOLT
4
169 N510017313AA
Hexagon socket head cap screw M3X16-10.9 A2J (Trivalent)
WASHER
4
170 N510018478AA
Small round-plain washer 3 10H A2J (Trivalent)
WASHER
2
171 N510018480AA
Small round-plain washer 5 10H A2J (Trivalent)
WASHER
4
172 N510018327AA Spring lock washer No.2 3 S A2J (Trivalent)
WASHER
2
173 N510018330AA Spring lock washer No.2 4 S A2J (Trivalent)
TERMINAL
1
181 N210001550AA
Manifold
1
191 N610026822AA Manifold:-X11
Valve
1
192 N610026824AA Valve:-F4014
M10
-0##
