Rhino SD2/XD2 Pumps 33 Part 1073520-12 E 2013 Nordson Corporation Notes:
Rhino SD2/XD2 Pumps
32
E 2013 Nordson Corporation
Part 1073520-12
NoteQtyDescriptionPartItem
— 1077362 Air Motor, 10-in., Rhino SD2/XD2 1
40 972151
S Ell, male, 37,
7
/
16
−20 x
1
/
8
1
41 984121
S Nut, hex, machine, #10-24
2
42 345862
S Washer, flat, Type-a, #10 narrow
2
43 1077364
S Pad, mounting, pneumatic trip, air motor, 10-in.
1
44 1077457
S Plate, alignment, pneumatic trip
1
45 345750
S Screw, socket,
1
/
4
−20 x 0.750
2
46 1062570
S Screw, set, socket, flat,
1
/
4
−20 x
3
/
8
2
47 1077363
S Lever, roller, pneumatic trip
2
48 983003
S Washer, flat, 0.156 x 0.312 x 0.032, 14456−CA
2
49 981944
S Screw, socket, 6-32 x 0.875
2
51 972583
S Ell, male, 37, 1
1
/
16
−12 x
3
/
4
1
50 - - - - - -
S O-ring, hot paint, 2 x 2.25 x 0.125
1
52 1063670
S Manifold, 10-in. air motor
1
53 1061490
S Valve, air pilot, 2-position, 5-port
1
54 972119
S Elbow, male,
1
/
4
tube x
1
/
8
NPT
2
55 303654
S Screw, socket,
5
/
16
−18 x 2.5
3
56 1063695
S Retainer, supply tube, 10-in. air motor
1
57 1063671
S Tube, air supply, 10-in. air motor
1
58 - - - - - -
S O-ring, hot paint, 1.250 x 1.438 x 0.094
1
59 1073943
S Tubing, 4 mm, Nylon, Series-N, flex, clear
3 ft
60 939110
S Strap, cable, 0.875 diameter
2
61 1060290
S Y-union,
5
/
32
1
62 1062560
S Screw, pan head, 10-32 x 0.375
6
63 1062215
S Cover, trip-rod, air motor
1
64 1010810
S Tubing,
1
/
4
OD polyethylene, flame resistant
1.6 ft
65 - - - - - -
S Plate, identification
1
66 981745
S Screw, drive, 0.187
2
67 1031834
S Lubricant, TFE grease, 5-lb, 1-gal
AR
68 900464
S Adhesive, Loctite 242, blue, removable, 50 ml
AR
69 900481
S Adhesive, pipe/thd/hyd sealant PST
AR
70 1069010
S Ell, pipe, 45, street, 1
1
/
4
, brass
2
71 - - - - - -
S O-ring, Viton, 0.739 ID x 0.070 w, brown, 10418
1
72 1077465
S Connector, plug-in, elbow, male, 4 mm
3
AR: As Required
Rhino SD2/XD2 Pumps
33
Part 1073520-12
E 2013 Nordson Corporation
Notes:
Rhino SD2/XD2 Pumps
34
E 2013 Nordson Corporation
Part 1073520-12
5.8 Cubic Inch Standard and
Temperature Conditioned Hydraulic Sections
See Figure 19 and the following parts list parts.
1
2
3
4
5
8
9
10
22
21
12
11
13
14
15
16
18
19
11
20
20
20
20
21
PARTS ARE INCLUDED IN THESE KITS:
SD2/XD2 5.8 CUBIC INCH PACKING GLAND SERVICE KIT 1104726
PARTS ARE INCLUDED IN THESE KITS:
SD2 5.8 CUBIC INCH DRIVE TRAIN SERVICE KIT 1105066
XD2 5.8 CUBIC INCH DRIVE TRAIN SERVICE KIT 1105065
A
A
6
7
PARTS ARE INCLUDED IN THESE KITS:
SD2/XD2 5.8 CUBIC INCH PACKING GLAND INTERNAL PARTS SERVICE KIT 1081134
17
23
24
Figure 19 5.8 Cubic Inch Standard Hydraulic Section Parts
