Nordson_EFD_Rhino_SD2_XD2_Operating Manual - 第42页

Rhino SD2/XD2 Pumps 38 E 2013 Nordson Corporation Part 1073520-12 8.1 Cubic Inch Stainless Steel Hydraulic Section See Figure 21 and the following parts list. 1 2 3 4 8 11 12 23 13 14 15 16 17 18 19 20 21 22 22 22 9 10 5…

100%1 / 50
Rhino SD2/XD2 Pumps
37
Part 1073520-12
E 2013 Nordson Corporation
Item Part Part Part Part Description Qty Note
— 1081133
1.625 diameter,
8.1 cubic inch, Rhino SD2
1
— 1085369
1.625 diameter, 8.1 cubic inch,
Rhino SD2, temperature conditioned
1
— 1081132
1.625 diameter,
8.1 cubic inch, Rhino XD2
1
— 1085368
1.625 diameter, 8.1 cubic inch,
Rhino XD2, temperature conditioned
1
1 1011324 1011324 1011324 1011324
S Chamber, solvent
1
2 1015987 1015987 1015987 1015987
S O ring, −149, Viton
1
3 1053264 1053264 1053264 1053264
S Screw, socket, 1/2−13 x 2
6
4 - - - - - - - - - - - - - - - - - - - - - - - -
S Gland assembly, tri-lip,
1.625 diameter, flange mount
1
5 1013172 1013172 1013172 1013172
S Body, pump, upper, 1.625/1.375
1
6 - - - - - - - - - - - - - - - - - - - - - - - -
S Screw, drive, 0.187
2
7 - - - - - - - - - - - - - - - - - - - - - - - -
S Plate, identification
1
8
1015822 1015822
S Rod, plunger,
1.625 diameter, chrome
1
1053014 1053014
S Rod, plunger,
1.625 diameter, Score Guard
1
9 1011340 1011340 1011340 1011340
S Piston assembly, 1.625 diameter
1
10 1101794 1101794 1101794 1101794
S Rod assembly, 1.625 diameter
1
11 1015989 1015989 1015989 1015989
S O ring, −144, Viton
2
12 1011346 1011346 1011346 1011346
S Cylinder, pump housing, 1.625
1
13 1075048 1075048 1075048 1075048
S Spacer,
shaft support, 1.625 diameter
1
14
1011349 1011349
S Plate, lower check, 1.625 diameter
1
1053043 1053043
S Plate, lower check,
1.625 diameter, Score Guard
1
15 1011347 1011347 1011347 1011347
S Housing, bottom, pump, 1.625
diameter
1
16 1015986 1015986 1015986 1015986
S O ring, −150, Viton
1
17 1011360 1011360 1011360 1011360
S Plate, housing, follower, 1.625/1.375
1
18 1032764 1032764 1032764 1032764
S Plate,
shovel, follower, 1.625 diameter
6
19 1015990 1015990 1015990 1015990
S Screw, socket, 1/2−13 x 12
6
20 900223 900223 900223 900223
S Lubricant,
O ring, Parker, 4 oz, 30122−5
1
21 900344 900344 900344 900344
S Lubricant, Never Seez, 8−oz can
1
22 900464 900464 900464 900464
S Adhesive,
Loctite 242, blue, removable, 50 ml
1
23 1085380 1085380
S Coil, temperature conditioned pump
1
24 1085225 1085225
S Cover,
temperature conditioned pump
1
Rhino SD2/XD2 Pumps
38
E 2013 Nordson Corporation
Part 1073520-12
8.1 Cubic Inch Stainless Steel Hydraulic Section
See Figure 21 and the following parts list.
1
2
3
4
8
11
12
23
13
14
15
16
17
18
19
20
21
22
22
22
9
10
5
7
6
22
22
23
23
14
22
PARTS ARE INCLUDED IN XD2 8.1 CUBIC INCH STAINLESS STEEL PACKING GLAND SERVICE KIT 1074331.
PARTS ARE INCLUDED IN XD2 8.1 CUBIC INCH ARW STAINLESS STEEL DRIVE TRAIN SERVICE KIT 1074332.
23
24
23
Figure 21 8.1 Cubic Inch Stainless Steel Hydraulic Parts
Rhino SD2/XD2 Pumps
39
Part 1073520-12
E 2013 Nordson Corporation
Item Part Description Qty Note
— 1058351 Pump, Rhino XD2, 1.625 diameter, 8.1 cubic inch, stainless steel, ARW 1
1 1011324
S Chamber, solvent
1
2 1015987
S O ring, −149, Viton,
1
3 1029126
S Screw, socket, 1/2−13 x 2.5
6
4 1058473
S Collar, ARW gland, rhino XD2, 1.625 diameter
1
5 − − − − − −
S Gland assembly, ARW, stainless steel
1
6 981628
S Screw, set, with Nylok, 3/8-16 x 1
2
7 972889
S Elbow, male, ext, 1/4 T x 1/8 NPT
2
8 1058323
S Body, pump, upper, stainless steel 1.625/1.375
1
9 − − − − − −
S Plate, identification
1
10 − − − − − −
S Screw, drive, 0.187
2
11 1058330
S Rod, plunger, 1.625 diameter, stainless steel, Score Guard
1
12 1600419
S Rod, lower check/shovel, 1.625 diameter, stainless steel
1
13 1058325
S Cylinder, pump housing, 1.625, stainless steel
1
14 1015989
S O ring, −144, Viton
2
15 1058331
S Spacer, shaft support, 1.625 diameter, stainless steel
1
16 1058332
S Plate, lower check, 1.625 diameter, Score Guard, stainless steel
1
17 1058326
S Housing, bottom, pump, 1.625 diameter, stainless steel
1
18 1015986
S O ring, −150, Viton,
1
19 1058328
S Plate, housing, follower, 1.625/1.375, stainless steel
1
20 1058327
S Plate, shovel, follower, 1.625 diameter
1
21 1053045
S Screw, socket, 1/2−13 x 12
6
22 156289
S Lubricant, Mobil SHC 634, 30122−8
AR
23 900344
S Lubricant, Never Seez, 8−oz can
1
24 900481
S Adhesive, pipe
1
Tools
The following tools are available for the Rhino SD2/XD2 pumps.
Item Kit Part
5.8 Cubic Inch
Hydraulic Sections
Removal arbor, packing gland internal parts 1073580
Insertion tool, gland packing internal parts 1081096
Insertion tool, packing gland replacement 1073589
8.1 Cubic Inch
Hydraulic Sections
Removal arbor, packing gland internal parts 1073582
Insertion tool, gland packing internal parts 1081097
Insertion tool, packing gland replacement 1035823
8.1 Cubic Inch
Stainless Steel
Hydraulic Section
Insertion tool, packing gland replacement 1035823
