Rhino SD2/XD2 Pumps 40 E 2013 Nordson Corporation Part 1073520-12 Kits The following kits are available for the Rhino SD2/XD2 pumps. Item Kit Part Air Motor Seals 1073577 5.8 Cubic Inch Hydraulic Sections SD2 Drive T rai…
Rhino SD2/XD2 Pumps
39
Part 1073520-12
E 2013 Nordson Corporation
Item Part Description Qty Note
— 1058351 Pump, Rhino XD2, 1.625 diameter, 8.1 cubic inch, stainless steel, ARW 1
1 1011324
S Chamber, solvent
1
2 1015987
S O ring, −149, Viton,
1
3 1029126
S Screw, socket, 1/2−13 x 2.5
6
4 1058473
S Collar, ARW gland, rhino XD2, 1.625 diameter
1
5 − − − − − −
S Gland assembly, ARW, stainless steel
1
6 981628
S Screw, set, with Nylok, 3/8-16 x 1
2
7 972889
S Elbow, male, ext, 1/4 T x 1/8 NPT
2
8 1058323
S Body, pump, upper, stainless steel 1.625/1.375
1
9 − − − − − −
S Plate, identification
1
10 − − − − − −
S Screw, drive, 0.187
2
11 1058330
S Rod, plunger, 1.625 diameter, stainless steel, Score Guard
1
12 1600419
S Rod, lower check/shovel, 1.625 diameter, stainless steel
1
13 1058325
S Cylinder, pump housing, 1.625, stainless steel
1
14 1015989
S O ring, −144, Viton
2
15 1058331
S Spacer, shaft support, 1.625 diameter, stainless steel
1
16 1058332
S Plate, lower check, 1.625 diameter, Score Guard, stainless steel
1
17 1058326
S Housing, bottom, pump, 1.625 diameter, stainless steel
1
18 1015986
S O ring, −150, Viton,
1
19 1058328
S Plate, housing, follower, 1.625/1.375, stainless steel
1
20 1058327
S Plate, shovel, follower, 1.625 diameter
1
21 1053045
S Screw, socket, 1/2−13 x 12
6
22 156289
S Lubricant, Mobil SHC 634, 30122−8
AR
23 900344
S Lubricant, Never Seez, 8−oz can
1
24 900481
S Adhesive, pipe
1
Tools
The following tools are available for the Rhino SD2/XD2 pumps.
Item Kit Part
5.8 Cubic Inch
Hydraulic Sections
Removal arbor, packing gland internal parts 1073580
Insertion tool, gland packing internal parts 1081096
Insertion tool, packing gland replacement 1073589
8.1 Cubic Inch
Hydraulic Sections
Removal arbor, packing gland internal parts 1073582
Insertion tool, gland packing internal parts 1081097
Insertion tool, packing gland replacement 1035823
8.1 Cubic Inch
Stainless Steel
Hydraulic Section
Insertion tool, packing gland replacement 1035823
Rhino SD2/XD2 Pumps
40
E 2013 Nordson Corporation
Part 1073520-12
Kits
The following kits are available for the Rhino SD2/XD2 pumps.
Item Kit Part
Air Motor Seals 1073577
5.8 Cubic Inch
Hydraulic Sections
SD2 Drive Train 1105066
SD2 CE Drive Train 1083820
XD2 Drive Train 1105065
XD2H Drive Train 1083817
SD2/XD2 Internal Packing Gland Parts
NOTE: This kit only includes the internal packing gland parts.
1081134
SD2/XD2 CE Internal Packing Gland Parts
NOTE: This kit only includes the internal packing gland parts.
1083818
SD2/XD2 Packing Gland Assembly
NOTE: This kit includes packing gland and the internal packing gland parts.
NOTE: Refer to the Rhino SD2/XD2 Packing Gland Replacement operator’s
card 1075674 for more data.
1104726
SD2/XD2 CE Packing Gland Assembly
NOTE: This kit includes packing gland and the internal packing gland parts.
NOTE: Refer to the Rhino SD2/XD2 Packing Gland Replacement operator’s
card 1075674 for more data.
1083819
XD2H Internal Packing Gland Parts
NOTE: This kit only includes the internal packing gland parts.
1083815
XD2H Packing Gland Assembly
NOTE: This kit includes packing gland and the internal packing gland parts.
NOTE: Refer to the Rhino SD2/XD2 Packing Gland Replacement operator’s
card 1075674 for more data.
1083816
8.1 Cubic Inch
Hydraulic Sections
SD2 Drive Train 1105067
XD2 Drive Train 1105068
Internal Packing Gland Parts
NOTE: This kit only includes the internal packing gland parts.
1081135
Packing Gland Assembly
NOTE: This kit includes the packing gland and internal packing gland parts.
NOTE: Refer to the Rhino SD2/XD2 Packing Gland Replacement operator’s
card 1075674 for more data.
1104731
8.1 Cubic Inch
Stainless Steel
Hydraulic Sections
Drive Train, XD2 Stainless Steel 1074332
XD2 Stainless Steel Packing Gland Assembly
XD2 Stainless Steel Packing Gland Internal Components
NOTE: Refer to the Rhino XD2 Stainless Steel Packing Gland Replacement
operator’s card 1081653 for more data.
1074331
1603003
Rhino SD2/XD2 Pumps
41
Part 1073520-12
E 2013 Nordson Corporation
Mounting Hardware
The following Mounting Hardware is available for
the pump.
30/55-Gallon Drum Unloaders
See Figure 22 and refer to the following parts list.
1
2
3
5
3
2
4
Figure 22 30/55-Gallon Drum Mounting Hardware
Item Part Description Qty
— 1069893 Pump, mounting to frame,
30/55-gallon
—
1 981664
S Screw,
7
/
8
-14 x 4.5
2
2 983501
S Washer, lock,
7
/
8
4
3 983254
S Washer, flat,
0.938 x 1.75 x 0.134
4
4 345719
S Screw,
7
/
8
-14 x 3
2
5 126751
S Rod, mounting
2
5-Gallon Pail Unloaders
See Figure 23 and refer to the following parts list.
1
2
3
Figure 23 5-Gallon Pail Mounting Hardware
Item Part Description Qty
— 1070032 Pump, mounting to frame,
5-gallon
—
1 345719
S Screw,
7
/
8
-14 x 2.75
2
2 983501
S Washer, lock,
7
/
8
2
3 983254
S Washer, flat,
0.938 x 1.75 x 0.134
2
