5.6. Anvil Unit
DA8MEC-Y4-400-A0
5.6.1 Anvil Unit
Unit No. N610069727AA
No.
Name Type
1.
qA axis (+) limit
EE-SX672
2.
qA axis (-) limit
EE-SX672
3.
qA axis origin detection
EE-SX672
3.
1.
2.
