RL131
MAINTENANCE MANUAL
7.2 Periodic Inspection Items
DA8MEC-Z0-020-A0
7.2-7
7.2.5 5,000-hour Check Items
The following table summarizes the periodic inspection items that are to be performed every 5000 hours.
For the details of inspection positions and lubrication method, refer to the subsequent sections.
Numbers in the Unit column show the relevant sections to be referred to.
Oiling (Every 5000 hours)
Unit No.
Item Task
Oiling
volume
Description
7.4.2
Insertion Drive
Unit
3.
Worm reduction gear
0.18 L
(Inside the
reduction
gear)
Replace the lubricant inside the
reduction gear.
Drain oil: Open the lock valve at the
bottom of the worm
reduction gear to drain old
oil.
Feed oil: After draining oil, pour new
oil from the oil port at the
top of the worm reduction
gear. (up to the middle of
the check window)
7.6.4
Part Processing
Drive Unit
3.
Worm reduction gear
0.18 L
(Inside the
reduction
gear)
Replace the lubricant inside the
reduction gear.
Drain oil: Open the lock valve at the
bottom of the worm
reduction gear to drain old
oil.
Feed oil: After draining oil, pour new
oil from the oil port at the
top of the worm reduction
gear. (up to the middle of
the check window)
7.7.2
Anvil Drive Unit
3.
Worm reduction gear
0.18 L
(Inside the
reduction
gear)
Replace the lubricant inside the
reduction gear.
Drain oil: Open the lock valve at the
bottom of the worm
reduction gear to drain old
oil.
Feed oil: After draining oil, pour new
oil from the oil port at the
top of the worm reduction
gear. (up to the middle of
the check window)
RL131
MAINTENANCE MANUAL
7.2 Periodic Inspection Items
DA8MEC-Z0-020-A0
7.2-8
7.2.6 Waste Disposal (whenever Filled)
The following table summarizes the disposal of wastes to be performed whenever filled.
For the details of inspection positions and lubrication method, refer to the subsequent sections.
Numbers in the Unit column show the relevant sections to be referred to.
Inspection (When Filled)
Unit No.
Item Task Description
a.
Tape waste receptacle
Dispose of tape wastes.
(Depending on the production amount, dispose of
tape wastes once a shift or once a day.)
7.8.1
Cut Waste Bottle
and Tape Waste
Receptacle
b.
Lead cut waste bottle
Dispose of tape wastes.
(Depending on the production amount, dispose of
tape wastes once a shift or once a day.)
RL131
MAINTENANCE MANUAL
7.3 PCB Transfer Unit
DA8MEC-Z4-000-A0
7.3-1
7.3. PCB Transfer Unit
DA8MEC-Z4-000-A0
7.3.1 X-Y Table
Unit No. N610055746AA
Oiling
Period
No.
Item Task
Oiling
volume
Description
1.
Ball screw (X)
Monthly
2.
Ball screw (Y)
3 cm
3
each
Position: Thread
3.
LM guide (X)
2 cm
3
each
4.
LM guide (Y)
2 cm
3
each
Position: Rail surface
3
months
5.
LM guide
0.25 cm
3
2. Ball screw (Y)
5. LM guide
1. Ball screw (X)
3. M guide (X)
4. LM guide (Y)
