RL131 MAINTENANCE MANUAL 10.1 Precautions in Disposi ng of Gas Dam pers DA8MEC-A1-06 0-A0 10.1-2
RL131
MAINTENANCE MANUAL
10.1 Precautions in Disposing of Gas Dampers
DA8MEC-A1-060-A0
10.1-1
Drill
10.1. Precautions in Disposing of Gas Dampers
DA8MEC-A1-060-A0
10.1.1 Removing Gas Dampers
This machine utilizes gas dampers for opening/closing the cover.
Since the gas dampers include high pressure gas, do not disassemble nor throw them in fires.
Before disposing of them, be sure to degas the cylinder.
Location
Removing Procedure
Step
Operation Result, reference drawing, etc.
1.
Remove the bolts securing the gas
damper to detach the gas damper.
2.
Using a drill of the specified
diameter, punch a hole at the
position shown in the drawing to
degas the gas damper.
Do not discard it until degassing is
completed.
Bolt
RL131
MAINTENANCE MANUAL
10.1 Precautions in Disposing of Gas Dampers
DA8MEC-A1-060-A0
10.1-2
RL131
MAINTENANCE MANUAL
10.2 Synthetic Resin Parts
DA8MEC-A1-020-A0
10.2-1
10.2. Synthetic Resin Parts
DA8MEC-A1-020-A0
The RG131 employs the synthetic resin parts listed in the table below.
Parts List
Name Product code Process
Constituent Weight
(g)
Quan-
tity
Remarks
Front cover N210078542AA
Cut Polycarbonate
1,930 1 Main unit cover
(1,156522t3.2)
Cover N210071272AB
Cut Polycarbonate
1,462 2 L&UL cover
(494323t52)
Cover N210100769AA
Cut Polycarbonate
1,956 2 Part supply unit
cover
(982230t52)
Handle N210086225AA
Molded Polypropylene
polyamide
665 1 Main drive unit
Timing belt N510035529AA
Molded Chloroplane
rubber
polyamide
106 1 Drive unit
Timing belt N6411875-608 Molded Chloroplane
rubber
polyamide
375 1 Drive unit
Timing belt N510035528AA
Molded Chloroplane
rubber
polyamide
392 1 Drive unit
Timing belt N510027678AA
Molded Chloroplane
rubber
polyamide
282 1 Insertion head/Anvil
Drive unit
Pallet X02P51500 Molded Polyacetal
(Duracon)
23.597=
2,279.5
97 Part transfer unit
Timing belt N210088858AA
Molded &
cut
(Material code
unknown)
Iron rubber
1,520 1 Part transfer unit
Container N510040711AA
Molded Polyethylene 2,600 2 Tape waste
receptacle
555´395´310
