RL131 MAINTENANCE MANUAL 2.8 Precautions at Service I nterruption DA8MEC-10-090- A0 2.8-2
RL131
MAINTENANCE MANUAL
2.8 Precautions at Service Interruption
DA8MEC-10-090-A0
2.8-1
2.8. Precautions at Service Interruption
DA8MEC-10-090-A0
2.8.1 Automatic Operation after Service Interruption
If the service has been interrupted during automatic operation, turn the main switch OFF to prevent
malfunction after power is recovered.
Operating Procedures
1.
1. Turn ON the main switch.
2. Set the <SERVO> switch in the OFF position.
3. Remove PC boards from the X-Y table, right rail or left rail.
4. Turn OFF the head brake switch and turn the H axis using the handwheel to adjust the angle of the cycle
timer at the machine origin (0° - 10°).
=REMARKS=
At this point, check that the position of the T axis is correct.
When the T axis is slanted, adjust the position of the T axis by hand before rotating the H axis using
the handwheel.
5. Close all safety covers (front, safety covers).
6. Set the <SERVO> switch in the ON position.
7. Reset the safety stop.
Press <ENABLING> + <START>.
8. Return the axes to their origins.
Press [Origin return] of [Machine adjustment].
9. Select [Production].
Press [Production].
10. Start production.
Press <ENABLING> + <START>.
RL131
MAINTENANCE MANUAL
2.8 Precautions at Service Interruption
DA8MEC-10-090-A0
2.8-2
RL131
MAINTENANCE MANUAL
3. INSTALLATION
DA8MEC-11-000-A0
3-1
3. INSTALLATION
