SIPLACE GEM SW Version GEM 505.01
HOST Interface Manual
©Siemens AG, all rights reserved page 127 of 236
4.10 Stream 8
not used
SIPLACE GEM SW Version GEM 505.01 HOST Interface Manual
Page 128 of 236 ©Siemens AG, all rights reserved
4.11 Stream 9
4.11.1 S9F1 - Unrecognized Device ID
S9F1 * H<-E
<B [10] MHEAD> . * MHEAD - Header of bad msg
4.11.2 S9F3 - Unrecognized
S9F3 * H<-E
<B [10] MHEAD> . * MHEAD - Header of bad msg
4.11.3 S9F5 - Unrecognized
S9F5 * H<-E
<B [10] MHEAD> . * MHEAD - Header of bad msg
4.11.4 S9F7 - Invalid Data
S9F7 * H<-E
<B [10] MHEAD> . * MHEAD - Header of bad msg
4.11.5 S9F9 - Transaction Timer
S9F9 * H<-E
<B [10] SHEAD> . * SHEAD - Stored Header
4.11.6 S9F11 - Data Too Long
S9F11 * H<-E
<B [10] MHEAD> . * MHEAD - Header of bad msg
SIPLACE GEM SW Version GEM 505.01
HOST Interface Manual
©Siemens AG, all rights reserved page 129 of 236
4.12 Stream 10
4.12.1 S10F1 - Terminal Request
S10F1 [W] * H<-E
<L [2]
<B [1] TID> * Terminal ID
<A [160] TEXT> * Message Text
> .
The Equipment sends text to the Host. This Equipment may send the following values for
TID:
TID Description
0x00 Always sent.
Equipment Constant "WBitS10" controls whether the Equipment sends S10F1 with W-Bit
"1" (Reply Expected) or "0" (No Reply Expected).
4.12.2 S10F2 - Terminal Request Acknowledge
S10F2 * H->E
<B [1] ACKC10> . * Acknowledge Code
The Host may send the following values for ACKC10:
ACKC10 Description
0x00 Normal. Host accepts the S10F1.
Other Host rejects the S10F1.
4.12.3 S10F3 - Terminal Display,
S10F3 [W] * H->E
<L [2]
<B [1] TID> * Terminal ID
<A [160] TEXT> * Message Text
> .
The Host sends to the Equipment. The Equipment interprets TID as follows:
TID Description
Any Equipment displays the text on its CRT.
The Host may optionally set the W-Bit to "1" in S10F3. If so, the Equipment replies with
S10F4.
4.12.4 S10F4 - Terminal Display Single Acknowledge
S10F4 * H<-E
