SIPLACE GEM SW Version GEM 505.01 HOST Interface Manual
Page 144 of 236 ©Siemens AG, all rights reserved
5.2.9 Host Requests Report by CEID
Step SECS Message Description
1. H -> E S6F15 W Request Event Report. The Host requests a
report for the specified CEID. In this way, the
host requests the Equipment to „pretend that
the specified CEID has occurred.
2. H <- E S6F16 The Equipment sends reports linked to that
CEID.
5.2.10 Host Requests Annotated Report by CEID
Step SECS Message Description
1. H -> E S6F17 W Request Annotated Event Report. The Host
requests a report for the specified CEID. In
this way, the host requests the Equipment to
„pretend“ that the specified CEID has
occurred.
2. H <- E S6F18 The Equipment sends annotated reports linked
to that CEID.
5.2.11 Host Requests Report by RPTID
Step
SECS Message Description
1.
H -> E S6F19 W Request Report. The Host requests a report
for the specified RPTID.
2.
H <- E S6F20 The Equipment sends the report.
5.2.12 Host Requests Annotated Report by RPTID
Step SECS Message Description
1. H -> E S6F21 W Request Annotated Report. The Host requests
an annotated report for the specified RPTID.
2. H <- E S6F22 The Equipment sends the annotated report.
5.2.13 Are You There
Step SECS Message Description
1. H -> E S1F1 W Are You There. The Host sends this simple
message.
2. H <- E S1F2 The Equipment reports its MDLN and
SOFTREV.
SIPLACE GEM SW Version GEM 505.01
HOST Interface Manual
©Siemens AG, all rights reserved page 145 of 236
5.2.14 Host Reads Equipment
Step SECS Message Description
1. H -> E S2F13 W Host requests the values of one or more
Equipment Constants.
2. H <- E S2F14 The Equipment responds with the values of the
requested Equipment Constants.
5.2.15 Host Sets Equipment Constants
Step SECS Message Description
1. H -> E S2F15 W Host sends new values for one or more
Equipment Constants.
2. H <- E S2F16 If all new values are valid, the Equipment saves
the new values and sends this message with an
acknowledge code of „0“. If one or more new
values are not valid, no Equipment Constants
are changed and the acknowledge code in this
message is non-zero.
SIPLACE GEM SW Version GEM 505.01 HOST Interface Manual
Page 146 of 236 ©Siemens AG, all rights reserved
5.3 Alarms
5.3.1 Equipment Reports Alarm
Step SECS Message Description
1. H <- E S5F1 [W] If reporting for this alarm ID is disabled, skip this
and the following step. Otherwise send the
alarm. The Equipment Constant WBitS5
determines whether the W-bit is 0 or 1 in this
message.
2. H -> E S5F2 If the W-bit in S5F1 is 1, the Host acknowledges
the alarm report. Otherwise, skip this step.
3. H <- E S6F11 W If the event ID associated with this alarm state is
enabled, send the event report. Otherwise, the
scenario ends.
4. H -> E S6F12 The Host acknowledges the event report.
5.3.2 Host Enables/Disables Alarms
Step SECS Message Description
1. H -> E S5F3 [W] The Host specifies ALIDs to be enabled or
disabled.
2. H <- E S5F4 If the W-bit in S5F3 is 1, the Equipment
acknowledges.
5.3.3 Host Requests Alarms
Step SECS Message Description
1. H -> E S5F5 W The Host requests whether specified ALIDs are
„on“ or „off“.
2. H <- E S5F6 The Equipment sends Alarm status.
