SIPLACE GEM SW Version GEM 505.01
HOST Interface Manual
©Siemens AG, all rights reserved page 159 of 236
ObjectId Name
25 Traceability
VID Class Format Name and Description
Fiducials
412002 SV L FIDUCIALDATA
Result from the last fiducial measurement
<L
<U1 FiducalName>
<I1 Quality> [1 - 100]
<U4 X-position> [1/1000 mm]
<U4 Y-position> [1/1000 mm]
<U4 X-deviation> [1/1000 mm]
<U4 Y-deviation> [1/1000 mm]
>
In case of an ink spot x-position, y-position, x-
deviation, y-deviation and quality are not valid.
For a detailed description of the data item see „4.2
Data Item Dictionary“.
An empty list indicates an error.
SIPLACE Transport
612001 SV U1 INPUTCONVEYORSTATE
The state of the input conveyor.
0 = Empty
1 = Full
2 = Error
612012 SV U1 FIRSTPROCESSINGCONVEYORSTATE
The state of the first processing conveyor.
0 = Empty
1 = Full
2 = Error
612013 SV U1 INTERMEDIATECONVEYORSTATE
The state of the intermediate conveyor
0 = Empty
1 = Full
2 = Error
612014 SV U1 SECONDPROCESSINGCONVEYORSTATE
The state of the second processing conveyor.
SIPLACE GEM SW Version GEM 505.01 HOST Interface Manual
Page 160 of 236 ©Siemens AG, all rights reserved
VID Class Format Name and Description
0 = Empty
1 = Full
2 = Error
612003 SV U1 OUTPUTCONVEYORSTATE.
The state of output conveyor.
0 = Empty
1 = Full
2 = Error
612004 SV U1 TWININPUTCONVEYORSTATE.
The state of the input conveyor on twin side
0 = Empty
1 = Full
2 = Error
612022 SV U1 TWINFIRSTPROCESSINGCONVEYORSTATE
The state of the first processing conveyor on twin side
0 = Empty
1 = Full
2 = Error
612023 SV U1 TWININTERMEDIATECONVEYORSTATE
The state of the intermediate conveyor on twin side
0 = Empty
1 = Full
2 = Error
612024 SV U1 SECONDPROCESSINGCONVEYORSTATE
The state of the second processing conveyor on twin
side
0 = Empty
1 = Full
2 = Error
612006 SV U1 TWINOUTPUTCONVEYORSTATE.
The state of output conveyor on twin side.
0 = Empty
1 = Full
2 = Error
612007 SV I4 TRANSPORTWIDTH
transport width [1/1000 mm]
A value of -1 indicates an error
Only valid after width has been measured or adjusted
by line computer
SIPLACE GEM SW Version GEM 505.01
HOST Interface Manual
©Siemens AG, all rights reserved page 161 of 236
VID Class Format Name and Description
612008 SV I4 TWINTRANSPORTWIDTH
transport width [1/1000 mm] on twin side
A value of -1 indicates an error
Only valid after width has been measured or adjusted
by line computer
Matrix Tray Changer (MTC)
812002 SV L MTCINFO
<L
<U1 MTC_number> valid for all MTC Events
<I2 tower>
<I2 carrier_modul>
<I2 level>
<I2 division>
<I4 Filling_level>
>
If you have several MTCs you can identify a MTC by
MTC_number. A MTC has 2 towers (1,2) and on every
tower there are several carrier modules. A carrier
module contains several tray carriers. Each tray
carrier can be identified by a level number. A tray
carrier consists of many divisions, wich can be
identified by the division number.
Filling_level is only valid with the Event
MTCfillLevelChanged.
In case of the Event MTCfillLevelChanged
carrier_modul will be -1.
Barcode
912002 SV A BCININPUTCONVEYOR
Barcode read from PCB in input conveyor. If no
barcode reader is installed in SIPLACE this variable
will contain an empty text
An empty text indicates an error.
912003 DV A COMPONENTBARCODE
Component barcode is read by the GUI.
An empty text indicates an error or barcode is read by
Mobile Verifier
912004 DV U2 WAYOFINPUTCOMPONENTBARCODE
Way of reading the component barcode:
1: with keyboard
2: with barcode reader
3: no barcode read
