SIPLACE GEM SW Version GEM 505.01 HOST Interface Manual
Page 162 of 236 ©Siemens AG, all rights reserved
VID Class Format Name and Description
Is not valid for Mobile Verifier
912005 SV U2 PCBSIDEININPUTCONVEYOR
Side of the PCB showing the barcode (only valid in
case of two barcode reader per conveyor)
1: above
2: down
3: barcode reader manufctured by LEUTZE in use or
the barcode could not be read
912006 SV U2 PCBSIDEINCENTERCONVEYOR
Side of the PCB showing the barcode (only valid in
case of two barcode reader per conveyor)
1: above
2: down
3: barcode reader manufctured by LEUTZE in use or
the barcode could not be read
912012 SV A BCINTWININPUTCONVEYOR
Barcode read from PCB in twin input conveyor. If no
barcode reader is installed in SIPLACE this variable
will contain an empty text.
An empty text indicates an error.
912015 SV U2 PCBSIDEINTWININPUTCONVEYOR
Side of the PCB showing the barcode (only valid in
case of two barcode reader per conveyor)
1: above
2: down
3: barcode reader manufctured by LEUTZE in use or
the barcode could not be read
912017 EC U1 BCREADEREXIST
Unables/Enables the event messages of the BCread
and BCTwinRead events.
0: No BCread and BCTwinRead events send
1: BCread and BCTwinRead events send (default)
912021 SV A PCBBCProc1Conv1
Barcode of PCB in progress in processing area 1 on
conveyor 1.
If no barcode reader is installed or no PCB is in
progress this variable will contain an empty text.
912021 SV A PCBBCProc1Conv2
Barcode of PCB in progress in processing area 1 on
conveyor 2.
If no barcode reader is installed or no PCB is in
progress this variable will contain an empty text.
SIPLACE GEM SW Version GEM 505.01
HOST Interface Manual
©Siemens AG, all rights reserved page 163 of 236
VID Class Format Name and Description
912021 SV A PCBBCProc2Conv1
Barcode of PCB in progress in processing area 2 on
conveyor 1.
If no barcode reader is installed or no PCB is in
progress this variable will contain an empty text.
912021 SV A PCBBCProc2Conv2
Barcode of PCB in progress in processing area 2 on
conveyor 2.
If no barcode reader is installed or no PCB is in
progress this variable will contain an empty text.
GEM-Kernel
1002001 DV A GEMEVENTTEXT.
The equipment will set this string to contain a
description of the most recent event. The Host can
include this variable in any event report it defines.
Communication Model
1002002 EC U1 INITCOMMSTATE.
Initial (power-up) Communications State.
0 = Disabled
1 = Enabled
1002003 EC U2 ESTABLISHCOMMUNICATIONSTIMER.
Time in seconds of how long the equipment will pause
after an unsuccessful Connect Request before
sending another. Valid values are 0-32000.s
1002004 EC U1 CONFIGCONNECT.
An EC which controls which SECS message this
Equipment will use for Connect Request.
0 = S1F1
1 = S1F65
2 = S1F13
Control State Model
1002005 EC U1 INITCONTROLSTATE.
Initial (power-up) control superstate.
1 = Off-Line
2 = On-Line
1002006 SV U1 CONTROLSTATE.
The current Control State.
1 = Off-Line/Equipment Off-Line
2 = Off-Line/Attempt On-Line
3 = Off-Line/Host Off-Line
4 = On-Line/Local
5 = On-Line/Remote
SIPLACE GEM SW Version GEM 505.01 HOST Interface Manual
Page 164 of 236 ©Siemens AG, all rights reserved
VID Class Format Name and Description
1002007 SV U1 PREVIOUSCONTROLSTATE.
The Control State in effect before the most recent
transition to the current Control State.
1 = Off-Line/Equipment Off-Line
2 = Off-Line/Attempt On-Line
3 = Off-Line/Host Off-Line
4 = On-Line/Local
5 = On-Line/Remote
1002008 EC U1 ONLINEFAILED.
The default Control State transition when Attempt On-
Line fails.
1 = Equipment Off-Line
3 = Host Off-Line
1002009 EC U1 ONLINESUBSTATE.
The default (power-up) online substate of the Control
State Model.
4 = Local
5 = Remote
1002010 EC U1 OFFLINESUBSTATE.
The default (power-up) offline substate of the Control
State Model.
1 = Equipment Off-Line
2 = Attempt On-Line
3 = Host Off-Line
1002056 SV A OPERATORCMDINRMOTESTATE
The last command issued by the Operator while the
Control state is „Remote“.
An empty text indicates that there was no operator
command in remote state since the last start of the
SIPLACE.
1002057 SV U1 CONTROLMODE
The actual control mode at the SIPLACE. This SV
indicates which software system is allowed to
download placement programs.
1 = none
2 = the „GEM-Host“
3 = the line computer (LCU)
4 = SIPLACE Pro
Process State Model
1002011 SV U1 PROCESSSTATE.
The current Process State.
