SIPLACE GEM SW Version GEM 505.01 HOST Interface Manual

VID Class Format Name and Description

Default value is "SIPLACE"

Can be overwritten with an individual name for each

machine.

1002069 SV I8 LASTERRORCODE

If the General Error Event FM_GENERAL is used, this

Variable contains the Error Code. The Error Code is

identical to the CEID of the specific Error Event.

Example:

A barcode reading error can be reported with the

Event

CEID 920001 FM_LP_BC_NOK

or with the General Error Event

CEID 1001024 FM_GENERAL and the Variables

VID 1002069 LASTERRORCODE = 920001 and

VID 1002070 LASTFMTEXT = "FM_LP_BC_NOK"

1002070 SV A LASTFMTEXT

Error Text of the last specific Error Event. For a

detailed description see LASTERRORCODE

1002071 SV A SOFTWAREREVMTC

Software revision of the Matrix Tray Changer

Only valid after a download of the MTC firmware.

Process Program Management

1002080 SV A CURRENTSETUP

Name of current setup loaded in machine

An empty text indicates an error.

1002081 SV A FIRSTCURRENTPLACEPROGRAM

Name of current placement program loaded in

machine for Processing 1 Area.

This data item will be set when a new Process

Program is downloaded to a SIPLACE machine for the

corresponding processing area and

a PCB reaches

the corresponding processing conveyor:

An empty text indicates an error.

1002082 SV A SECONDCURRENTPLACEPROGRAM

Name of current placement program loaded in

machine for Processing 2 Area.

An empty text indicates an error.

1002942 EC U4 MAX_TIME_TO_STOP

max. spoolingtime in minutes, if safespoolmode ist

SIPLACE GEM SW Version GEM 505.01

HOST Interface Manual

VID Class Format Name and Description

activ

1002943 EC U1 SAFE_SPOOL_MODE

0 = inactiv

1 = aktiv

GUI

1122001 SV A GUIACTIONTEXT

Last „Action text“ sent to GUI

An empty text indicates an error

1122002 SV A GUISTATETEXT

Last „State text“ sent to GUI

An empty text indicates an error

1122007 SV U4 GUIMESSAGENUMBER

Used for General GUI Events CEID 1120300 and

1120301

Contains the CEID of the special GUI Event.

E.g. in case of GUIStart you may use either Event

1120007 GUIStart or Event MessageFromGuiGeneral

with VID 1122007 (GUIMESSAGENUMBER) which

will contain the value 1120007.

13xxxxx

14xxxxx

23xxxxx

24xxxxx

SIPLACE Head 1

SIPLACE Head 2

SIPLACE Head 3

SIPLACE Head 4

1312001

1412001

2312001

2412001

SV I4 HEIGHTHEAD1

HEIGHTHEAD2

HEIGHTHEAD3

HEIGHTHEAD4

Height of placement head x.

Only valid after reference run. Units are 1/1000 mm

During the reference run the SIPLACE measures the

distance between the upper edge of the conveyor belt

and the nozzle on segment 1. The HEIGHTHEADx is

then calculated by subtracting the length of the nozzle

on segment 1 from the measured value. The nozzle

length is defined in the machine data. So

HEIGHTHEADx is a relative not an absolute value.

A value of 0 indicates an error

1312002

1412002

2312002

2412002

SV L GANTRYINFO1

GANTRYINFO2

GANTRYINFO3

GANTRYINFO4

Gantry information for head 1. The data is

SIPLACE GEM SW Version GEM 505.01 HOST Interface Manual

VID Class Format Name and Description

automatically reseted when a PCB reaches the

corresponding processing conveyor.

CompPickedUp Number of components which

were picked up successfully since

the last PCB reached the center

conveyor

CompPlaced Number of components which

were placed since the last PCB

reached the center conveyor

CompLeft2Place Number of components which

were not placed on the actual

PCB

An empty list indicates an error.

For a detailed description of the data item see „4.2

Data Item Dictionary“.

1312003

1412003

2312003

2412003

SV L PLACEINFO1

PLACEINFO2

PLACEINFO3

PLACEINFO4

Placement information for head x.

L <

<U4 X-position> [1/1000 mm]

<U4 Y-position> [1/1000 mm]

<F8 Angle> [1/100 degrees]

<I4 PlacementVacuum> [mbar]
