SIPLACE GEM SW Version GEM 505.01 HOST Interface Manual Page 178 of 236 ©Siemens AG, all rights reserved VID Class Format Name and Description 2012018 SV U2 ERRORINFO2 Additional information about an error event. Corresp…

SIPLACE GEM SW Version GEM 505.01

HOST Interface Manual

VID Class Format Name and Description

....

(for each segment)

... .

are not valid for TwinHead

The first element in this list refers to segment 1, the

second to segment 2 and so on. If a segment was not

in use in the last placement cycle the list for that

segment is left empty.

Miscellaneous

2012013 SV U2 ERRORTYPE

Type of the most recent error

2 Transport

3 Track error

4 Machine error

5 Miscellaneous

A value of 0 indicates an error.

2012014 SV U2 GANTRYONERROR

Gantry associated with the most recent error (1...4)

A value of 0 indicates an error.

2012015 SV U2 SEGMENTONERROR

Segment number associated with the most recent

error (1...12)

A value of 0 indicates an error.

2012016 SV U2 TRACKONERROR

Track number associated with the most recent error

event

A value of 0 indicates an error.

2012017 SV U2 ERRORINFO1

Additional information about an error event.

Corresponds to the first parameter of an error

message on the station computer.

SIPLACE GEM SW Version GEM 505.01 HOST Interface Manual

VID Class Format Name and Description

2012018 SV U2 ERRORINFO2

Additional information about an error event.

Corresponds to the second parameter of an error

message on the station computer.

2012021 SV L GANTRYHEADCONFIG

<I2 GantryGroupID

...

TypeOfGantry:

At the moment there is only 1 Type of Gantry.

TypeOfGantry is always = 1

HEADTYPE:

4 = TwinHead with 2 nozzles

5 = Revolverhead with 12 nozzles

6 = Revolverhead with 6 nozzles

7 = IC Head

For a detailed description of the data item see „4.2

Data Item Dictionary“.

2012022 DV U1 MACHINESIDE

For a detailed description of the data item see „4.2

Data Item Dictionary“.

2012023 DV I2 TRACKNUMBER

For a detailed description of the data item see „4.2

Data Item Dictionary“.

2012024 DV I2 DIVISION

SIPLACE GEM SW Version GEM 505.01

HOST Interface Manual

VID Class Format Name and Description

For a detailed description of the data item see „4.2

Data Item Dictionary“.

2012025 DV I2 LEVEL

For a detailed description of the data item see „4.2

Data Item Dictionary“.

2012026 DV U1 SEGMENT

For a detailed description of the data item see „4.2

Data Item Dictionary“.

2012027 DV A COMPONENTNAME

For a detailed description of the data item see „4.2

Data Item Dictionary“.

2012028 DV U2 GANTRYID

For a detailed description of the data item see „4.2

Data Item Dictionary“.

2012029 DV U2 GANTRYGROUPID

For a detailed description of the data item see „4.2

Data Item Dictionary“.

2012030 DV U2 HEADID

For a detailed description of the data item see „4.2

Data Item Dictionary“.

2012031 DV A REFERENCEDESIGNATOR

For a detailed description of the data item see „4.2

Data Item Dictionary“.

2012032 DV U2 PACKAGEFORMNUMBER

For a detailed description of the data item see „4.2

Data Item Dictionary“.

2012033 DV U2 PLACEERRORDESCRIPTION

For a detailed description of the data item see „4.2

Data Item Dictionary“.

2012035 DV U1 LOCATION

For a detailed description of the data item see „4.2

Data Item Dictionary“.

2012037 SV L PICKUPERRORSLOC1

Pick-Up Errors of location 1 (see 1.6 machine areas).

This data item will be reset when a new Process

Program is downloaded to a SIPLACE machine for the

corresponding processing area and

a PCB reaches

the corresponding processing conveyor:

processing 1 area (S25)

processing 1 area (HS50)

processing 1 area (HF).
