SIPLACE GEM SW Version GEM 505.01 HOST Interface Manual ©Siemens AG, all rights reserved page 181 of 236 VID Class Format Name and Description <U2 FeederAccessesPerPCB> <U2 VacuumErrors> <U2 OpticalErrors&…
SIPLACE GEM SW Version GEM 505.01 HOST Interface Manual
Page 180 of 236 ©Siemens AG, all rights reserved
VID Class Format Name and Description
<L
<A ComponentName>
<I2 TrackNumber>
<U2 FeederType>
<I2 Level>
<I2 Division>
<U1 Tower>
<U2 FeederAccessesPerPCB>
<U2 VacuumErrors>
<U2 OpticalErrors>
<U2 CoplanarityErrors>
>
....
>
FeederAccessesPerPCB will be reset when a PCB
reaches the corresponding processing conveyor.
If the component was picked up from a feeder Level
and Tower will contain -1.
In the case that the component was picked up from a
tray in the matrix tray changer TrackNumber will be -1
and Level and Tower are valid.
For a detailed description of the data item see „4.2
Data Item Dictionary“.
An empty list indicates an error.
2012038 SV L PICKUPERRORSLOC2
Pick-Up Errors of location 2 (see 1.6 machine areas).
This data item will be reset when a new Process
Program is downloaded to a SIPLACE machine for the
corresponding processing area and
a PCB reaches
the corresponding processing conveyor:
processing 1 area (S25)
processing 2 area (HS50)
processing 2 area (HF).
<L
<L
<A ComponentName>
<I2 TrackNumber>
<U2 FeederType>
<I2 Level>
<I2 Division>
<U1 Tower>
SIPLACE GEM SW Version GEM 505.01
HOST Interface Manual
©Siemens AG, all rights reserved page 181 of 236
VID Class Format Name and Description
<U2 FeederAccessesPerPCB>
<U2 VacuumErrors>
<U2 OpticalErrors>
<U2 CoplanarityErrors>
>
....
>
FeederAccessesPerPCB will be reset when a PCB
reaches the corresponding processing conveyor.
If the component was picked up from a feeder Level
and Tower will contain -1.
In the case that the component was picked up from a
tray in the matrix tray changer TrackNumber will be -1
and Level and Tower are valid.
For a detailed description of the data item see „4.2
Data Item Dictionary“.
An empty list indicates an error.
2012039 SV L PICKUPERRORSLOC3
Pick-Up Errors of location 3 (see 1.6 machine areas).
This data item will be reset when a new Process
Program is downloaded to a SIPLACE machine for the
corresponding processing area and
a PCB reaches
the corresponding processing conveyor:
processing 1 area (S25)
processing 2 area (HS50)
processing 2 area (HF).
<L
<L
<A ComponentName>
<I2 TrackNumber>
<U2 FeederType>
<I2 Level>
<I2 Division>
<U1 Tower>
<U2 FeederAccessesPerPCB>
<U2 VacuumErrors>
<U2 OpticalErrors>
<U2 CoplanarityErrors>
>
....
SIPLACE GEM SW Version GEM 505.01 HOST Interface Manual
Page 182 of 236 ©Siemens AG, all rights reserved
VID Class Format Name and Description
>
FeederAccessesPerPCB will be reset when a PCB
reaches the corresponding processing conveyor.
If the component was picked up from a feeder Level
and Tower will contain -1.
In the case that the component was picked up from a
tray in the matrix tray changer TrackNumber will be -1
and Level and Tower are valid.
For a detailed description of the data item see „4.2
Data Item Dictionary“.
An empty list indicates an error.
2012040 SV L PICKUPERRORSLOC4
Pick-Up Errors of location 4 (see 1.6 machine areas).
This data item will be reset when a new Process
Program is downloaded to a SIPLACE machine for the
corresponding processing area and
a PCB reaches
the corresponding processing conveyor:
processing 1 area (S25)
processing 1 area (HS50)
processing 1 area (HF).
<L
<L
<A ComponentName>
<I2 TrackNumber>
<U2 FeederType>
<I2 Level>
<I2 Division>
<U1 Tower>
<U2 FeederAccessesPerPCB>
<U2 VacuumErrors>
<U2 OpticalErrors>
<U2 CoplanarityErrors>
>
....
>
FeederAccessesPerPCB will be reset when a PCB
reaches the corresponding processing conveyor.
If the component was picked up from a feeder Level
and Tower will contain -1.
In the case that the component was picked up from a
tray in the matrix tray changer TrackNumber will be -1
and Level and Tower are valid.
